AC142FCBHA / AC182FCBHA
No. Specialized Number Name Quantity
1 001A0100330 Inlet grill 1
2 001A2400087 Air filter 2
3 001A1301395 Reinforced rod 1
4 001A1301399 Pinch plate 2
5 001A17001180
6 001A1231181 Front panel 1
7 001A1431586 Display panel 1
8 001A1444589 Receive window 1
9 001A1431587 Indicating lamp-shaded 13
10 001A1431588 Cover for indicator panel 1
11 001A1742772A Rod board 1
12 001A0100331 Frame of air outlet grill 1
13 001A1431593 Long pole 1 1
14 001A1431594 Long pole 2 1
15 001A1431593 Blade 1 1
16 001A1431594 Blade 2 1
17 001A1431599 Blade(small) 13
18 001A1431598 Crank link 1
19 001A1431595 Frame for step motor 1
20 001A3000107 Stepping motor 1
21 001A1431605 Irregular board 1
22 001A1431602 Long pole assembly 1 1
23 001A1431603 Long pole assembly 1 1
24 001A1231192 Sub-drain pan 1
25 001A1301388 Partition plate(up) 1
26 001A1233191 Drain pan 1
27 001A1436607 Lock 1
28 001A1301396 Fixed press strip 1
29 0010701137 Evaporator assy 1
30 001A1231183 Support plate(Left) 1
31 001A1231184 Support plate(Right) 1
32 001A1231182 Top plate 1
33 001A1436606 Handle 4
34 001A1101098 Back rear frame assembly 1
35 001A1301400 Evaporator fixed-board(Left) 1
36 001A13011226 Evaporator fixed-board(Right) 1
37 001A1101104 Mounting plate(Right) 1
38 001A1101103 Mounting plate(Left) 1
39 001A100610 Partition plate(down) 2
40 001A1301381 Frame for motor 1
41 001A0100608 Motor braket assembly 1
42 001A1301382 Motor pressure pad 2
43 001A3000109 Motor 1
44 001A1431608 Worm shell(down) 2
45 001A1431609 Worm shell(up) 2
46 001A2300042 Centrifugal fan 2
47 001A0100609 Electrical box cover assy 1
48
49 001A3600009B Motor capacitor 1
50 0010450416 PCB 1
51 001A4000177 Terminal block (6 bites) 1
52 001A1301378 Electrical box 1
53 001A14311292 Power supply nip 1
54 001A1734865 Evaporator pad(Left) 1
001A3800141
Fixed board
1
Transformer
1
