NO. Specialized number Name of part QTY

1 0010800954 front grill 1

2 0010201169 air filter 1

3 0010201288 button 1

4 0010800923 front panel 1

5 0010751105 heat exchanger 1

6 *0010850276 temperature sensor 1

7 0010800928 motor cover 1

8 0010201176 bearing 1

9 0010201176 bearing 1

10 0010201191 flap 1

11 0010800930 air outlet assy 1

12 0010800924 bottom plate 1

13 0010800932 plate cushion 1

14 0010100571 back panel 1

15 001A5002008 screw 4

16 001A5002116 screw 5

17 001A5401031 screw washer 5

18 001A5002118 screw 2

19 0010400935 swing motor 1

20 0010400933 motor 1

21 *0010850276 display board 1

22 0010800928 motor cover 1

23 *0010850276 control box shell 1

24 *0010850276 control box 1

25 *0010850276 main board 1

26 *0010850276 power board 1

27 *0010850276 service cover 1

28 *0010850276 terminal block 1

29 *0010850276 wiring clamp 1

30 001A5002099 screw 3

31 001A5002236 screw 3

32 0010201275 hand switch 1

33 0010400928 select board 1

34 0010400934 motor 1

35 0010201209 flap 1

36 0010201208 drain pan assy. 1

37 0010201184 below fan 1

38 0010201175 up fan 1

39 0010400936 swing motor 1

40 0010201281 cover panel 1

41 001A5002236 screw 2

note: Part *0010850276 is of a assembly.
