Pedrollo TRITUS TRm 0.75 [8/8] Dimensions horizontal delivery version
![Pedrollo TRITUS TRm 0.75 [8/8] Dimensions horizontal delivery version](/views2/1828390/page8/bg8.png)
449
Ør
h
h2
h3
h1
a
p
i4
i3
i1
i2
DN
d
e
Øm
b
c
h
h1
i1
Øm
i2
i3
DN
h3
Øg
c
p
i6
i5
Øn
i5
i4
Øn
Øg
h2
a
b
MODEL PORT DIMENSIONS mm
Single-phase
Three-phase
DN a b c p h h1 h2 h3 i1 i2
i3 i4 i5 i6 Øg Øm Øn
TRm 0.75 TR 0.75
2"
210 61 17 392 405 50 165 130 85 94 40 16 50 48 ¾" 12 11
TRm 0.9 TR 0.9
TRm 1.1 TR 1.1
TRm 1.3 TR 1.3
TRm 1.5 TR 1.5
2"
216 61 17 401 489 40 165 130 85 94 40 16 50 48 ¾" 12 11
– TR 2.2
DIMENSIONS (Horizontal delivery version)
DIMENSIONS (Vertical delivery version)
MODEL PORT DIMENSIONS mm
Single-phase
Three-phase
DN a b c d e p h h1 h2 h3 i1 i2
i3 i4 i5 Øg Øm Øn Ør
TRm 0.75 TR 0.75
2½"
202 61 52 125 165 501 405 48 164 216 120 72 62 50 48 ¾" 14 11 18
TRm 0.9 TR 0.9
TRm 1.1 TR 1.1
TRm 1.3 TR 1.3
TRm 1.5 TR 1.5
2½"
212 61 52 125 165 515 489 38 164 216 120 72 62 50 48 ¾" 14 11 18
– TR 2.2
BASE PEDESTAL KIT TRITUS | 50 Hz
