Specifications
Owner’s Manual
153
Specifications
General Specifications
Sampling Frequency External
44.1kHz
+4.1667%, +0.1%, –0.1%, –4.0%
±200ppm
48kHz
+4.1667%, +0.1%, –0.1%, –4.0%
±200ppm
88.2kHz
+4.1667%, +0.1%, –0.1%, –4.0%
±200ppm
96kHz
+4.1667%, +0.1%, –0.1%, –4.0%
±200ppm
Signal Delay
Less than 3ms
INPUT to OUTPUT
*1
, connect with CL5 using Dante, Dante Receive Latency set to 0.25ms (one way),
Fs= 48kHz
*1. INPUT to OUTPUT means Ri8-D INPUT to Ro8-D OUTPUT
Frequency Response
+0.5, –1.5dB 20Hz-20kHz, refer to +4dBu output @1kHz, INPUT to OUTPUT
*1
, Fs= 44.1kHz, 48kHz
+0.5, –1.5dB 20Hz-40kHz, refer to +4dBu output @1kHz, INPUT to OUTPUT
*1
, Fs= 88.2kHz, 96kHz
Total Harmonic Distortion
*2
*2. Total Harmonic Distortion is measured with 18dB/octave filter @80kHz
Less than 0.05% 20Hz-20kHz@+4dBu into 600Ω, Fs= 44.1kHz, 48kHz
Less than 0.05% 20Hz-40kHz@+4dBu into 600Ω, Fs= 88.2kHz, 96kHz
INPUT to OUTPUT
*1
, Input Gain= Min.
Hum&Noise
*3
*3. Hum & Noise are measured with A-Weight filter.
–128dBu typ., Equivalent Input Noise, Input Gain= Max.
–88dBu Residual output noise, ST master off.
Dynamic Range
112dB typ., DA Converter,
108dB typ., INPUT to OUTPUT
*1
, Input Gain= Min.
Crosstalk@1kHz
–100dB
*4
, adjacent INPUT/OUTPUT channels, Input Gain= Min.
*4. Crosstalk is measured with a 30dB/octave filter @22kHz
Dimensions (WxHxD)
and Net Weight
Ri8-D: 480mm x 44mm x 362mm, 4.5kg
Ro8-D: 480mm x 44mm x 358.5mm, 4.4kg
Power Requirements
(wattage)
Ri8-D: 35W
Ro8-D: 35W
Power Requirements
(voltage and hertz)
US/Canada: 120V 60Hz
Japan: 100V 50/60Hz
China: 110-240V 50/60Hz
Korea: 220V 60Hz
Other: 110-240V 50/60Hz
Temperature Range
Operating temperature range: 0 - 40°C
Storage temperature range: –20 - 60°C
Included Accessories Owner’s Manual, Power Cord
