Unit CS-V24DKE CU-V24DKE
Thermostat Electronic Control Mechanical Control
Protection Device — Inner Protector
Capillary Tube Length mm — 645
Flow Rate l/min — 23.5
Inner Diameter mm — 2.0
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 45 µF, 400VAC
Fan Motor Capacitor µF, VAC — 3.5 µF, 450VAC
Note:
•
Specifications are subject to change without notice for further improvement.
9
CS-V18DKE CU-V18DKE / CS-V24DKE CU-V24DKE
