1 Features 2

2 Functions

2.1. Remote Control

2.2. Indoor Unit

2.3. Outdoor Unit

3 Product Specifications

3.1. CS-E15DKDW CU-E15DKD

3.2. CS-E18DKDW CU-E18DKD

3.3. CS-E21DKDS CU-E21DKD

4 Dimensions

4.1. Indoor Unit & Remote Control

4.2. Outdoor Unit

and distribution is a violation of law.

CS-E15DKDW CU-E15DKD

CS-E18DKDW CU-E18DKD

CS-E21DKDS CU-E21DKD

5 Refrigeration Cycle Diagram 15

6 Block Diagram

7 Wiring Diagram

8 Operation Details

8.1. Basic Function

8.2. Protection Control Features

9 Operating Instructions

9.1. CS-E15DKDW

9.2. CS-E18DKDW CS-E21DKDS

10 Installation And Servicing Air Conditioner Using R410A

10.1. Outline

10.2. Tools For Installing/Servicing Refrigerant Piping

Air Conditioner

CONTENTS

Page Page

Order No. MAC0501021C2

Содержание

Air conditioner 1
Contents 1
Cs e15dkdw cu e15dkd cs e18dkdw cu e18dkd cs e21dkds cu e21dkd 1
Page page 1
Auto restart control 2
Automatic air swing and manual adjusted by remote control for horizontal and vertical airflow 2
Breakdown self diagnosis function 2
Deice operation 2
Delay on timer and off timer 2
Environmental protection 2
Features 2
Four modes of operation selection 2
Gas leakage detection 2
Inactive various harmful airbone elements including allergens viruses and bacteria generated supersonic waves enhance the ability to collect dust and dirt in the air 2
Ionizer mode operation 2
Non ozone depletion substances refrigerant r410a 2
Powerful mode operation 2
Product 2
Quality improvement 2
Quiet mode operation 2
Removable washable front panel 2
Serviceability improvement 2
Supersonic air purifying system with super alleru buster 2
Airflow direction control 3
Check point 3
Clock setting 3
Functions 3
Indoor fan speed selection 3
Ion mode operation 3
Operation mode selection 3
Operation off on 3
Powerful mode operation 3
Quiet mode operation 3
Remote control 3
Reset point 3
Room temperature setting 3
Time timer setting 3
Timer operation set cancel 3
Timer setting 3
Automatic and 5 manual horizontal airflow directions 4
Automatic and 5 manual indoor fan speeds 4
Automatic and 5 manual vertical airflow directions 4
Automatic operation switch 4
Automatic restart control 4
Delay on timer and off timer 4
Four operation modes 4
Indoor unit 4
Ionizer control 4
Microcomputer controlled room temperature control 4
Operation indication lamps led 4
Powerful mode 4
Quiet mode 4
Outdoor unit 5
Cs e15dkdw cu e15dkd 6
Product specifications 6
Specifications are subjected to change without notice for further improvement 7
Cs e18dkdw cu e18dkd 8
Specifications are subjected to change without notice for further improvement 9
Cs e21dkds cu e21dkd 10
Specifications are subjected to change without notice for further improvement 11
Dimensions 12
Basic function 18
Internal setting temperature 18
Operation details 18
Table b outdoor air temperature shifting 19
Table c powerful mode shifting 19
Table d quiet lo mode shifting 19
Table e fan speed shifting 19
Table f start up shifting 19
Best amenity control 20
Comphz freq a freq h freq c 20
Compressor is off when intake air temperature internal setting temperature 1 c 20
Compressor off point 0 c 20
Compressor operation frequency 20
Cooling operation 20
Every 90s cooling 120s heating maintain same zone freq h 1 until fc 46 fh 39 20
Example calculation 20
Model no e18dk 20
Operating frequency calculation formula 20
Operation mode cooling 20
Remarks 20
Thermostat control 20
When freq h is equal to 46 cooling 39 heating or above the comp may run at the freq higher than fc or fh up to max freq operation 20
When intake air temperature internal setting temperature 1 c 20
Automatic operation 21
Heating operation 21
Soft dry operation 21
Thermostat control 21
A basic rotation speed rpm 22
Cooling dry fan 22
Heating 22
Indoor fan motor operation 22
Required rotation speed for fan is set to respond to the remote control setting 10 rpm unit 22
The operation mode chart for this example is as shown in below figure and the operation mode to be performed will depend on indoor intake air temperature and outdoor air temperature at the time when the judgment is made 22
There is a temperature shifting on t1 t2 and t3 if the operation mode judged is changed from cooling soft dry to heating or vice verse 22
Values of t1 t2 and t3 depend on remote control setting temperature as shown in below table after the adjustment of t1 t2 and t3 values the operation mode for that particular environment and remote control setting is judged and performed based on the above operation mode chart every 30 minutes 22
Control at cooling dry operation and auto fan speed 26
D deodorizing control 26
I control condition 26
Ii operation 26
No deodorizing control is performed during on timer standby operation and during anti freezing control prevention 26
Outdoor fan motor is operated with 15 fan speed it starts when compressor starts operation and it stops 30 seconds after compressor stops operation 26
Outdoor fan motor operation 26
The odor status is arranged as below and it is shifted as follow 26
Airflow direction 27
Basic rotation speed 27
Control of airflow direction can be automatic angles of direction is determined by operation mode heat exchanger temperature and intake air temperature and manual angles of direction can be adjusted using remote control 27
There are two types of airflow vertical airflow directed by horizontal vane and horizontal airflow directed by vertical vanes 27
Vertical airflow 27
Automatic horizontal airflow direction can be set using remote control the vane swings left and right within the angles as stated below for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below 28
Automatic vertical airflow direction can be set using remote control the vane swings up and down within the angles as stated above for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below when the air conditioner is stopped using remote control the vane will shift to close position 28
Horizontal airflow 28
Manual horizontal airflow direction can be set using remote control the angles of the vane are as stated below and the positions of the vane are as figure 2 above 28
Manual vertical airflow direction can be set using remote control the angles of the vane are as stated above and the positions of the vane are as figure 2 below when the air conditioner is stopped using remote control the vane will shift to close position 28
Quiet operation cooling mode cooling area of dry mode 29
Quiet operation under soft dry operation dry area at dry mode 29
Quiet operation heating 30
Delay off timer control 31
Delay on timer control 31
Powerful mode operation 31
Auto operation switch 32
Auto restart control 32
If ionizer led is blinking there is an abnormality of ionizer occurs 32
If power led is blinking the possible operations of the unit are hot start during deice operation operation mode judgment or delay on timer sampling 32
If timer led is blinking there is an abnormality operation occurs 32
Indication panel 32
This type of control is not applicable during on off timer setting 32
When the power supply is cut off during the operation of air conditioner the compressor will re operate within three to four minutes there are 10 patterns between 2 minutes 58 seconds and 3 minutes 52 seconds to be selected randomly after power supply resumes 32
When the switch is pressed between 0 to 5 seconds auto mode operation starts to function 32
When the switch is pressed between 11 to 16 seconds and together with the signal from remote control timer decrement button for 5s the unit can be changed to different controlling setting 4 type of transmission codes 32
When the switch is pressed between 16 to 21 seconds either h14 error detection selection mode or the remote control signal receiving sound can be cancelled or turned on 32
When the switch is pressed between 5 to 8 seconds the unit is forced to operate in cooling mode 32
When the switch is pressed between 8 to 11 seconds the unit will enter forced heating mode standby press timer decrement button for 5s for the unit to operate in heating mode 32
Indoor power relay control 33
Ionizer operation 33
C timer during ionizer operation 34
Case 1 34
I purpose 34
Ii two types of problem detection control 34
Ionizer operation case study 34
Ionizer problem detection control 34
Refer to case study in next page for detail 34
To inform user of ionizer problems and detection 34
Without ionizer operation 34
30 seconds forced operation 35
However if total outdoor unit running current exceeds y value compressor will be stopped immediately for three minutes 35
However it can be stopped using remote control or auto switch at indoor unit 35
If the running current does not exceed x value for five seconds the frequency instructed will be increased 35
Once the compressor starts operation it will not stop its operation for 30 seconds 35
Protection control features 35
Protection control for all operations 35
The compressor will not start for three minutes after stop of operation 35
The first 30 minutes of cooling operation a will be applied 35
This control is not applicable if the power supply is cut off and on again or after 4 way valve deices condition 35
Time delay safety control 35
Total running current control 35
When the outdoor unit total running current ac exceeds x value the frequency instructed for compressor operation will be decreased 35
A overheating prevention control 36
B dc peak current control 36
Compressor operation restarts after three minutes the temperature decreases to 95 c 36
Compressor overheating prevention control 36
If the set value is exceeded again more than 30 seconds after the compressor starts the operation will restart after two minute 36
If the set value is exceeded again within 30 seconds after the compressor starts the operation will restart after one minute if this condition repeats continuously for seven times all indoor and outdoor relays will be cut off 36
If this phenomenon is continuously occurring for twice within 20 minutes all indoor and outdoor relays will be cut off 36
Instructed frequency for compressor operation will be regulated by compressor top temperature the changes of frequency are as below figure 36
Ipm power transistor prevention control 36
Low pressure prevention control gas leakage detection 36
This control is not applicable for deice operation 36
When electric current to ipm exceeds set value of 25 4 a the compressor will stop operate then operation will restart after three minutes 36
When the conditions listed in below table occur the compressor stops and restarts after three minutes 36
When the ipm temperature rises to 110 c compressor operation will stop immediately 36
A abnormal signal transmitted to indoor unit after 3 minutes outdoor power is supplied indoor unit stop 37
A total current is below 0 4 0 4 amp 37
B operating frequency is 72 hz e18dk 95 hz e21dk 1 and above 37
C continuously for 20s 37
Control cancellation condition 37
Control contents 37
Control starting condition 37
Ct disconnection detection 37
During cooling operation anti freezing control soft dry carry out the following operation 37
During heating operation operate the followings control 37
During powerful on 37
During remote control setting is less than 18 deg 37
During remote control setting is less than 28 deg 37
However when less than thermo off for 100 sec continuously the above control will be cancel 37
However when less than thermo off for 120 sec continuously the above control will be cancel 37
Low frequency protection control 1 37
Low frequency protection control 2 37
Minimum frequency protection control 37
Starting condition 1 is not fulfilled 37
When all the below conditions occur minimum value freq min for the frequency instructed to compressor will change to 30 hz 37
When the compressor operate at frequency lower than 22 hz for 240 minutes the operation frequency will be increased to 22 hz for two minutes 37
Cooling overload control 38
Outdoor air temperature control 38
Protection control for cooling soft dry operation 38
Anti dew formation control 39
Anti freezing control 39
Anti cold draft control 40
Protection control for heating operation 40
Intake air temperature control 41
Outdoor air temperature control 41
Outdoor temperature control 42
Overload protection control 42
Deice control 43
Cs e15dkdw 47
Installation precautions installation precautions 47
Operating instructions 47
Operation operation precautions precautions 47
Safety precautions 47
Air filter 48
Air inlet 48
Air intake 48
Air outlet 48
Airflow direction adjustment 48
Airflow direction louver 48
Auto off on button 48
Discharged air 48
Fan speed selection 48
Front panel 48
I about 48
Indicator 48
Indoor unit ndoor unit 48
Ion operation 48
Ionizer 48
Lcd display 48
Memory reset clock setting 48
Off on 48
Operation mode quiet operation 48
Outdoor outdoor unit unit 48
Powerful operation 48
Product overview 48
Receiver 48
Remote control remote control 48
Supersonic air purifying device 48
Temperature setting 48
Timer setting 48
Transmitter 48
Auto heat cool dry auto heat cool dry 49
Button again to stop the operation 49
G powerful quiet and ion operations could be activated in all operation modes 49
G press 49
G supersonic air purifying device super alleru buster operates automatically while the air conditioner is switched on 49
How to operate 49
Select the desired operation 49
Set the temperature 16 c 30 c 49
Start the operation 49
Adjust the vertical or horizontal airﬂ ow direction louver 50
Air swing air swing 50
Enables ion operation 50
Enables powerful operation 50
Enables quiet operation 50
Fan speed fan speed 50
G powerful and quiet operations could not be activated at the same time 50
G powerful quiet and ion operations could be cancelled by pressing the respective button again 50
How to operate 50
Ion ion 50
Powerful powerful 50
Powerful powerful quiet quiet ion fan speed ion fan speed 50
Quiet quiet 50
Select fan speed 50
Cancel cancel 51
Cancel the selected timer 51
Conﬁ rm the setting 51
G ensure the clock on the remote control has been set correctly 51
G to cancel either the on or off timer press 51
G you could use the on and off timers at the same time 51
How to operate 51
Select on or off timer 51
Set the desired time 51
Then press 51
Timer timer 51
Air filter air filter 52
Care cleaning 52
Clean with cotton bud 52
Front panel front panel 52
Indoor unit indoor unit 52
Ionizer ionizer 52
Raise and pull to remove wash and dry 52
Supersonic air supersonic air purifying device purifying device 52
Switch off the power supply switch off the power supply before cleaning before cleaning 52
Vacuum the super alleru buster ﬁ lter 52
Vacuum wash and dry 52
Vacuum wash and dry the frame 52
Wipe gently 52
Caution 53
Cs e18dkdw cs e21dkds 53
Installation precautions installation precautions 53
Operation operation precautions precautions 53
Safety precautions 53
Thank you for purchasing panasonic air conditioner 53
Warning 53
Air filter 54
Air inlet 54
Air intake 54
Air outlet 54
Airflow direction adjustment 54
Airflow direction louver 54
Auto off on button 54
Discharged air 54
Fan speed selection 54
Front panel 54
I about 54
Indicator 54
Indoor unit ndoor unit 54
Ion operation 54
Ionizer 54
Lcd display 54
Memory reset clock setting 54
Off on 54
Operation mode quiet operation 54
Outdoor outdoor unit unit 54
Powerful operation 54
Product overview 54
Receiver 54
Remote control remote control 54
Supersonic air purifying device 54
Temperature setting 54
Timer setting 54
Transmitter 54
Auto heat cool dry auto heat cool dry 55
Button again to stop the operation 55
G powerful quiet and ion operations could be activated in all operation modes 55
G press 55
G supersonic air purifying device super alleru buster operates automatically while the air conditioner is switched on 55
How to operate 55
Select the desired operation 55
Set the temperature 16 c 30 c 55
Start the operation 55
Adjust the vertical or horizontal airﬂ ow direction louver 56
Air swing air swing 56
Enables ion operation 56
Enables powerful operation 56
Enables quiet operation 56
Fan speed fan speed 56
G powerful and quiet operations could not be activated at the same time 56
G powerful quiet and ion operations could be cancelled by pressing the respective button again 56
How to operate 56
Ion ion 56
Powerful powerful 56
Powerful powerful quiet quiet ion fan speed ion fan speed 56
Quiet quiet 56
Select fan speed 56
Cancel cancel 57
Cancel the selected timer 57
Conﬁ rm the setting 57
G ensure the clock on the remote control has been set correctly 57
G to cancel either the on or off timer press 57
G you could use the on and off timers at the same time 57
How to operate 57
Select on or off timer 57
Set the desired time 57
Then press 57
Timer timer 57
Air filter air filter 58
Care cleaning 58
Clean with cotton bud 58
Front panel front panel 58
Indoor indoor unit unit 58
Ionizer ionizer 58
Raise and pull to remove wash and dry 58
Supersonic air supersonic air purifying device purifying device 58
Switch off the power supply switch off the power supply before cleaning before cleaning 58
Vacuum the super alleru buster ﬁ lter 58
Vacuum wash and dry 58
Vacuum wash and dry the frame 58
Wipe gently 58
A chemical characteristics the chemical characteristics of r410a are similar to those of r22 in that both are chemically stable non flammable refrigerants with low toxicity however just like r22 the specific gravity of r410a gas is heavier than that of air because of this it can cause an oxygen deficiency if it leaks into a closed room since it collects in the lower area of the room it also generates toxic gas when it is directly exposed to a flame so it must be used in a well ventilated environment where it will not collect 59
About r410a refrigerant 59
B compositional change pseudo azeotropic characteristics r410a is a pseudo azeotropic mixture comprising the two components r32 and r125 multi component refrigerants with these chemical characteristics exhibit little compositional change even from phase changes due to vaporization or condensation which means that there is little change in the circulating refrigerant composition even when the refrigerant leaks from the gaseous section of the piping accordingly r410a can be handled in almost the same manner as the single component refrigerant r22 however when charging because there is a slight change in composition between the gas phase and the liquid phase inside a cylinder or other container charging should basically begin with the liquid side 59
C pressure characteristics as seen in table 2 the gas pressure of r410a is approximately 1 times as high as that of r22 at the same refrigerant temperature which means that special r410a tools and materials with high pressure specifications must be used for all refrigerant piping work and servicing 59
Converting air conditioners to r410a since it was declared in1974 that chlorofluorocarbons cfc hydro chlorofluorocarbons hcfc and other substances pose a destructive danger to the ozone layer in the earth s upper stratosphere 20 to 40 km above the earth measures have been taken around the world to prevent this destruction the r22 refrigerant which has conventionally been used in acs is an hcfc refrigerant and therefore possesses this ozone destroying potential international regulations the montreal protocol on ozone damaging substances and the domestic laws of various countries call for the early substitution of r22 by a refrigerant which will not harm the ozone layer 59
In acs the hfc refrigerant which has become the mainstream alternative is called r410a compared with r22 the pressure of r410a is approximately 1 times as high at the same refrigerant temperature but the energy efficiency is about the same consisting of hydrogen h fluorine f and carbon c r410a is an hfc refrigerant another typical hfc refrigerant is r407c while the energy efficiency of r407c is somewhat inferior to that of r410a it offers the advantage of having pressure characteristics which are about the same as those of r22 and is used mainly in packaged acs 59
Installation and servicing air conditioner using r410a 59
Outline 59
The characteristics of hfc r410a refrigerants 59
1 always replace the dryer of the outdoor unit at the same time the replacement dryer is wrapped in a vacuum pack replace it last among the refrigerating cycle parts start brazing as soon as you have opened the vacuum pack and begin the vacuuming operation within 2 hours 60
1 you can use the conventional r22 flaring tool if you need to buy a new tool buy the r410a type 60
2 use when it is necessary to detect small gas leaks 60
After finishing the installation check to make sure there is no refrigerant gas leaking 60
Cause the gas pressure of r410a is approximately 1 times as high as that of r22 a mistake in installation or servicing could result in a major accident it is essential that you use r410a tools and materials and that you observe the following precautions to ensure safety 60
D r410a refrigerating machine oil conventionally mineral oil or a synthetic oil such as alkylbenzene has been used for r22 refrigerating machine oil because of the poor compatibility between r410a and conventional oils like mineral oil however there is a tendency for the refrigerating machine oil to collect in the refrigerating cycle for this reason polyester and other synthetic oils which have a high compatibility with r410a are used as refrigerating machine oil because of the high hygroscopic property of synthetic oil more care must be taken in its handling than was necessary with conventional refrigerating machine oils also these synthetic oils will degrade if mixed with mineral oil or alkylbenzene causing clogging in capillary tubes or compressor malfunction do not mix them under any circumstances 60
Do not perform any alterations on the ac unit under any circumstances have all repair work done by a specialist incorrect repairs can result in an water leakage electric shock fire etc 60
Do not use any refrigerant other than r410a in acs that have been used with r410a 60
For other installation work you should have the usual tools such as screwdrivers a metal cutting saw an electrical drill a hole core drill 65 or 70 dia a tape measure a level a thermometer a clamp meter an insulation tester a voltmeter etc 60
If any refrigerant gas leaks while you are working ventilate the room toxic gas may be generated if refrigerant gas is exposed to a direct flame 60
In order to prevent an r410a ac from mistakenly being charged with any other refrigerant the diameter of the 3 way valve service port on the outdoor unit has been changed also to increase its ability to withstand pressure the opposing dimensions have been changed for the refrigerant pipe flaring size and flare nut accordingly when installing or servicing refrigerant piping you must have both the r410a and ordinary tools listed below 60
Necessary tools 60
Safety measures when installing servicing refrigerant piping 60
Tools for installing servicing refrigerant piping 60
When installing or transferring an ac do not allow any air or substance other than r410a to mix into the refrigeration cycle if it does the pressure in the refrigeration cycle can become abnormally high possibly causing an explosion and or injury 60
When installing or transferring an ac follow the instructions in the installation instructions carefully incorrect installation can result in an abnormal refrigeration cycle or water leakage electric shock fire etc 60
Because the pressure is higher for the r410a type the conventional type cannot be used 61
Copper tube gauge for clearance adjustment used when flaring with the conventional flaring tool clutch type 61
Flaring tool clutch type 61
In the r410a flaring tool the receiving hole for the clamp bar is enlarged so the clearance from the clamp bar can be set to 0 0 mm and the spring inside the tool is strengthened to increase the strength of the pipe expanding torque this flaring tools can also be used with r22 piping so we recommend that you select it if you are buying a new flaring tool 61
Manifold gauge 61
R410a tools 61
The shape of the manifold ports has been changed to prevent the possibility of mistakenly charging with another type of refrigerant 61
This gauge makes it easy to set the clearance for the copper tube to 1 1 mm from the clamp bar of the flaring tool 61
Torque wrenches 61
R410a tools which are usable for r22 models 63
Piping materials 64
Processing and connecting piping materials 64
Refrigerant piping work 64
A check to make sure there is no scratches dust etc on the flare and union 65
A sheathed copper pipes and copper element pipes when using these pipes check to make sure that they are the stipulated thickness for flare nuts be sure to used the same nut that is used on the ac unit 65
B align the flared surface with the axial center of the union 65
Because the gas pressure of r410a is approximately 1 times as high as that of r22 copper pipes with the thickness shown in table 10 and with minimal impurities must be used care must also be taken during storage to ensure that pipes are not crushed deformed or scratched and that no dust moisture or other substance enters the pipe interior when storing sheathed copper pipes or plain copper pipes seal the openings by pinching or taping them securely 65
C use a torque wrench and tighten to the specified torque the tightening torque for r410a is the same as the conventional torque value for r22 be careful because if the torque is too weak it may lead to a gas leak if it is too strong it may split the flare nut or make it impossible to remove the flare nut 65
Makings and management 65
Procedure and precautions for flare connection 65
Storing and managing piping materials 65
Types of piping and their storage the following is a general classification of the refrigerant pipe materials used for acs 65
Inspecting gas leaks with a vacuum pump for new installations using new refrigerant piping 66
Installation transferring servicing 66
Ac units replacement using existing refrigerant piping 67
Refrigerant compatibility using r410a refrigerant in r22 acs and vice versa 67
Transferring using new refrigerant piping 67
Recharging refrigerant during servicing 68
Brazing 69
Servicing tips 69
Carry out test running to confirm that no abnormality occurs after the installation then explain to user the operation care and maintenance as stated in instructions please remind the customer to keep the operating instructions for future reference 70
Electrical work must be installed by a licensed electrician be sure to use the correct rating of the power plug and main circuit for the model to be installed 70
G cs e15dkdw 70
Installation instructions 70
Read the following safety precautions carefully before installation 70
Safety precautions 70
The caution items stated here must be followed because these important contents are related to safety the meaning of each indication used is as below incorrect installation due to ignoring of the instruction will cause harm or damage and the seriousness is classified by the following indications 70
The items to be followed are classified by the symbols 70
Warning 70
Attention 71
Caution 71
How to fix installation plate 73
Indoor unit 73
Indoor unit installation 73
Select the best location refer to select the best location section 73
To drill a hole in the wall and install a sleeve of piping 73
Connect the cable to the indoor unit 75
Connecting the piping 77
Install the outdoor unit 77
Outdoor unit 77
Select the best location refer to select the best location section 77
Connect the cable to the outdoor unit 78
Evacuation of the equipment 78
Pipe insulation 79
Check items 80
Carry out test running to confirm that no abnormality occurs after the installation then explain to user the operation care and maintenance as stated in instructions please remind the customer to keep the operating instructions for future reference 81
Electrical work must be installed by a licensed electrician be sure to use the correct rating of the power plug and main circuit for the model to be installed 81
G cs e18dkdw cs e21dkds 81
Installation instructions 81
Read the following safety precautions carefully before installation 81
Safety precautions 81
The caution items stated here must be followed because these important contents are related to safety the meaning of each indication used is as below incorrect installation due to ignoring of the instruction will cause harm or damage and the seriousness is classified by the following indications 81
The items to be followed are classified by the symbols 81
Warning 81
Attention 82
Caution 82
How to fix installation plate 84
Indoor unit 84
Indoor unit installation 84
Select the best location refer to select the best location section 84
To drill a hole in the wall and install a sleeve of piping 84
Connect the cable to the indoor unit 86
Connecting the piping 88
Install the outdoor unit 88
Outdoor unit 88
Select the best location refer to select the best location section 88
Connect the cable to the outdoor unit 89
Evacuation of the equipment 89
Pipe insulation 90
Check items 91
A cooling 92
B heating 92
Caution 92
During troubleshooting and servicing rated compressor operating frequency must be obtained in order to check the specification and technical data below are the methods used to obtain rated compressor operating specification 92
Press the auto button continuously for 8 seconds or less than 11 seconds the air conditioner starts operation at heating rated frequency beep beep will be heard at the 8th second 92
Rated frequency operation 92
Servicing information 92
Troubleshooting 92
Breakdown self diagnosis function 94
Button once next error code will be displayed press v button once previous error code will be displayed 94
By pressing the tmer 94
Carry on the measurements of pressure electric current and temperature fifteen minutes after an operation is started 94
If check button is press again or without any operation for 30 seconds the diagnosis mode will turn off 94
If error code displayed matches the error code saved in unit memory abnormality detected beep beep beep sounds will be heard for 4 seconds and power led will light on otherwise one beep sound is heard 94
Once abnormality detected during operation the unit will immediately stop its operation timer led is blinking and maximum of three error codes abnormality will be saved in memory the abnormality of the operation can be identified through the below breakdown diagnosis method 94
Press check button at remote control continuously for more than five seconds to turn on the diagnosis mode h11 will be displayed at remote control 94
Relationship between the condition of the air conditioner and pressure and electric current 94
Although operation forced to stop when abnormality detected emergency operation is possible for certain errors refer to error codes table by using remote control or auto switch at indoor unit however the remote control signal receiving sound is changed from one beep to four beep sounds 95
Error codes table 95
The memory data of error code is erased when the power supply is cut off or press the auto switch until beep sound heard following by pressing the reset button at remote control 95
Remote control 96
A indoor control board removal procedures 97
Disassembly of parts 97
Remove the front grille 97
Remove the indoor control board 97
B electronic controller removal procedures 98
C cross flow fan and fan motor removal procedures 98
Remove cross flow fan and fan motor 98
Remove main electronic controller 98
D outdoor electronic controller removal procedure 99
Remove the outdoor electronic controller 99
Remove the top panel and front panel 99
G cs e15dkdw cu e15dkd 103
G cs e18dkdw cu e18dkd 103
G cs e21dkds cu e21dkd 103
Sensible capacity chart 103
Cs e15dkdw 104
Exploded view indoor unit 104
Cs e18dkdw cs e21dkds 105
All parts are supplied from phaam malaysia vendor code 061 106
Cs e15dkdw 106
O marked parts are recommended to be kept in stock 106
Replacement parts list indoor unit 106
All parts are supplied from phaam malaysia vendor code 061 107
Cs e18dkdw cs e21dkds 107
O marked parts are recommended to be kept in stock 107
Cu e15dkd cu e18dkd cu e21dkd 108
Exploded view outdoor unit 108
All parts are supplied from phaam malaysia vendor code 061 109
Cu e15dkd cu e18dkd cu e21dkd 109
O marked parts are recommended to be kept in stock 109
Replacement parts list outdoor unit 109
Electronic circuit diagram 110
Indoor unit 110
Schematic diagram 1 4 110
Cs e15dkdw cu e15dkd cs e18dkdw cu e18dkd cs e21dkds cu e21dkd 111
Ic08 nr 111
Regulator 111
Schematic diagram 2 4 111
Cs e15dkdw cu e15dkd cs e18dkdw cu e18dkd cs e21dkds cu e21dkd 112
Ic01 a52d4956g133 112
Ic05 td62003af 112
Ic06 td62003af 112
Schematic diagram 3 4 112
Air cleaner complete 113
High voltage ionizer 113
Schematic diagram 4 4 113
Cs e15dkdw cu e15dkd cs e18dkdw cu e18dkd cs e21dkds cu e21dkd 114
G cu e15dkd cu e18dkd cu e21dkd 114
Outdoor unit 114
Schematic diagram 1 4 114
Cs e15dkdw cu e15dkd cs e18dkdw cu e18dkd cs e21dkds cu e21dkd 115
Q12 rt1n432 115
Q13 q11 115
Q4 2sc3052 115
Q7 2sc3441 115
Schematic diagram 2 4 115
Cs e15dkdw cu e15dkd cs e18dkdw cu e18dkd cs e21dkds cu e21dkd 116
Schematic diagram 3 4 116
Cs e15dkdw cu e15dkd cs e18dkdw cu e18dkd cs e21dkds cu e21dkd 117
Schematic diagram 4 4 117
How to use electronic circuit diagram 119

Panasonic CU-E18DKD Сервис мануал онлайн

Содержание

Похожие устройства
