Unit CS-E15DKDW CU-E15DKD
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G (gas side) ; 1/2”
L (liquid side) ; 1/4”
G (gas side) ; 1/2”
L (liquid side) ; 1/4”
Drain
Hose
Inner diameter mm 12 —
Length m 0.65 —
Power Cord Length
Number of core-wire
—— —
—
Dimensions Height inch (mm) 11 - 1/32 (280) 29 - 17/32 (750)
Width inch (mm) 31 - 15/32 (799) 34 - 7/16 (875)
Depth inch (mm) 7 - 7/32 (183) 13 - 19/32 (345)
Net Weight lb (kg) 20 (9) 106 (48)
Compressor Type — Involute scroll
Motor Type — Brushless (4-pole)
Rated Output W — 700
Air Circulation Type Cross-flow Fan Propeller Fan
Material ASHT-18 P.P
Motor Type Transistor (8-poles) Transistor (8-poles)
Rate Output W 30 40
Fan Speed Lo (Cool/Heat) rpm 980 / 1,160 —
Me (Cool/Heat) rpm 1,220 / 1,360 —
Hi (Cool/Heat) rpm 1,460 / 1,560 660 / 640
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coated)
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2/15 1/28
FPI 21 18
Size (W × H × L) mm 610 × 315 × 25.4 871.7 × 711.2 × 22
Refrigerant Control Device — Expansion Valve
Refrigeration Oil (c.c) — RB68A (360)
Refrigerant (R410A) kg (oz) — 1.06 (37.4)
Thermostat Electronic Control —
Protection Device Electronic Control Electronic Control
Length mm — —
Capillary Tube Flow Rate l/min — —
Inner Diameter mm — —
Air Filter Material
Style
P.P.
Honeycomb
—
•
Specifications are subjected to change without notice for further improvement.
