APP mode is compatible with the following
iPod models.
! iPhone 4 (software version 4.1 or later)
! iPhone 3GS (software version 4.1 or later)
! iPhone 3G (software version 4.1 or later)
! iPhone (software version 3.1.3 or later)
! iPod touch 3rd generation (software version
4.0 or later)
! iPod touch 2nd generation (software ver-
sion 4.0 or later)
! iPod touch 1st generation (software version
3.1.3 or later)
! While this function is in use, the iPod will
not turn off even if the ignition key is turned
off. Operate the iPod to turn off the power.
1 Switch the control mode to App Mode.
Refer to Introduction of video playback opera-
tions on page 14.
Refer to Introduction of sound playback opera-
tions on page 17.
2 Operate the connected iPod to select a
video/song and play.
Note
The following functions are still accessible from
the unit even if the control mode is set to
App Mode.
! Pausing
! Fast forwarding/reversing
! Tracking up/down
! Moving to a chapter up/down
Random play (shuffle)
iPod-videos/songs can be played back in ran-
dom order.
! Songs – Play back videos/songs in the se-
lected list in random order.
! Albums – Play back videos/songs from a
randomly selected album in order.
! Folder – Play back songs/tracks in the se-
lected folder in random order.
! Disc – Play back songs/tracks in the se-
lected disc in random order.
! On – Play back files in random order within
the repeat range, Folder and Disc.
! Off – Cancel random play.
Playing all songs in random
order (shuffle all)
(Function for iPod)
This method plays all songs on the iPod
randomly.
Repeating playback
! Disc – Play through the current disc
! Chapter – Repeat the current chapter
! Title – Repeat the current title
! Track – Repeat the current track
! File – Repeat the current file
! Folder – Repeat the current folder
! One – Repeat just the current video/song/
track
! All – Repeat all videos/songs in the se-
lected list on the iPod
Repeat all files
! This function cannot be operated during
Video CD playback featuring PBC (playback
control).
! If you perform chapter search, fast forward/
reverse, frame-by-frame playback or slow
motion playback, the repeat play will stop.
! When playing discs with compressed audio
and audio data (CD-DA), playback is re-
peated within the type of data currently
playing even if Disc is selected.
! If you select another folder during repeat
play, the repeat play range changes to Disc.
If you select USB or SD source, the repeat
play range changes to All.
! If you perform track search or fast forward/
reverse during File, the repeat play range
changes to Folder.
En
30
Section
12
Detailed instructions
