2 Touch Parametric EQ.
3 Touch a or b to select the desired item.
EQ (equalizer)—SP-Select (speakers)—Band
(bands)—Frequency (center frequency)—
Level (equalizer level)—Q. Factor (Q factor)
4 Touch d to select the equalizer.
Powerful—Natural—Vocal—Flat—Custom1
—Custom2—Super Bass
5 Touch b and then touch c or d to se-
lect the speaker to be adjusted.
Rear (rear speakers)—Center (center speaker)
—Front (front speakers)
# Speakers with the size set to Off cannot be se-
lected. (Refer to Setting the speaker setting on
page 51.)
6 Touch b and then touch c or d to se-
lect the equalizer band to be adjusted.
Low (low)—Mid (mid)—High (high)
7 Touch b and then touch c or d to se-
lect the center frequency of selected band.
40Hz—50Hz—63Hz—80Hz—100Hz—125Hz
—160Hz—200Hz—250Hz—315Hz—400Hz
—500Hz—630Hz—800Hz—1kHz—1.25kHz
—1.6kHz—2kHz—2.5kHz—3.15kHz—4kHz
—5kHz—6.3kHz—8kHz—10kHz—12.5kHz
8 Touch b and then touch c or d to ad-
just the equalizer level.
Range: +12 to –12
9 Touch b and then touch c or d to se-
lect the desired Q factor.
Narrow (narrow)—Wide (wide)
# Adjust the parameters of each band for the
other speakers in the same way.
Note
A center frequency can be selected for each
band and can be changed in 1/3-octave steps.
However, the interval between the selected center
frequencies cannot be shorter than 1 octave.
Using the auto-equalizer
The auto-equalizer is the equalizer curve cre-
ated by auto TA and EQ (refer to Auto TA and
EQ (auto-time alignment and auto-equalizing)
on this page) on this page).
You can turn the auto-equalizer on or off.
1 Display the DSP function menu.
Refer to Introduction of menu operations on
page 44.
2 Touch Auto EQ.
# You cannot use this function if auto TA and
EQ have not been carried out.
3 Touch d to turn the auto-equalizer on.
# To turn the auto-equalizer off, touch c.
Auto TA and EQ (auto-time
alignment and auto-equalizing)
Auto-time alignment automatically adjusts the
time alignment according to the distance be-
tween the listening position and each speaker.
The auto-equalizer automatically measures
the car’s interior acoustic characteristics, and
then creates an auto-equalizer cur ve based on
that information.
WARNING
As a loud tone (noise) may be emitted from the
speakers when measuring the car’s interior
acoustic characteristics, never perform auto TA
or auto EQ while driving.
CAUTION
! Thoroughly check the conditions before per-
forming auto TA and EQ as the speakers may
be damaged if these functions are performed
when:
— The speakers are incorrectly connected.
(For example, when a rear speaker is con-
nected as a subwoofer output.)
— A speaker is connected to a power amp de-
livering output higher than the speaker’s
maximum input power capability.
En
55
Section
13
Menu operations
Menu operations
