Ariston CE6VP4 [18/76] Start up and use
![Ariston CE6VP4 [18/76] Start up and use](/views2/1083933/page18/bg12.png)
18
GB
Start-up and use
The first time you use your appliance, heat the
empty oven with its door closed at its maximum
temperature for at least half an hour. Ensure that the
room is well ventilated before switching the oven off
and opening the oven door. The appliance may emit
a slightly unpleasant odour caused by protective
substances used during the manufacturing process
burning away.
Should the appliance be equipped with an electronic
programmer, to use the electric oven, just press the
and buttons at the same time (the symbol
will appear on the display) before selecting the
desired cooking function.
Before operating the product, remove all plastic film
from the sides of the appliance.
.
Setting the time*
1. Press the
PROGRAMMER knob
and turn it in a
clockwise direction to
set the correct time.
The clock can only be
set if the oven is
connected to the
electricity mains. In the
event of a power
failure, the PROGRAMMER will stop: the correct
time will need to be reset once the power has been
restored.
Starting the oven*
1. Turn the PROGRAMMER knob in a clockwise
direction until the ! symbol appears in the display
window.
2. Pull the PROGRAMMER knob and turn it in a
clockwise direction until the red pointer is aligned
with the current time. A click will indicate the end of
the programming phase.
3. Turn the PROGRAMMER knob in a clockwise
direction until the 9 symbol appears in the display
window.
4. Select the desired cooking mode using the
SELECTOR knob.
5. To switch the oven off, turn the SELECTOR knob
back to the "0" position.
Programming cooking*
Programming a cooking duration with immediate
start
1. Turn the PROGRAMMER knob in a clockwise
direction until the desired cooking duration appears
in the display window.
2. Select the desired cooking mode using the
SELECTOR knob. The oven switches on immediately
and remains in operation for the entire set cooking
duration.
3. When the selected time period has elapsed, a
buzzer will sound. To silence it, turn the
PROGRAMMER knob in a clockwise direction until
the ! symbol appears in the display window.
4. Turn the SELECTOR knob to the "0" position.
For example: it is 9:00 a.m. and a duration of 1
hour and 15 minutes is programmed. The
programme will stop automatically at 10:15 a.m.
Programming a cooking duration with delayed
start
1. Turn the PROGRAMMER knob in a clockwise
direction until the ! symbol appears in the display
window.
2. Pull the PROGRAMMER knob and turn it in a
clockwise direction until the red pointer is aligned
with the desired cooking start time.
3. Turn the PROGRAMMER knob in a clockwise
direction until the desired cooking duration appears
in the display window.
4. Select the desired cooking mode using the
SELECTOR knob. The oven will switch on at the set
cooking start time and will remain on for the entire
set cooking duration.
5. When the selected time period has elapsed, a
buzzer will sound. To silence it, turn the
PROGRAMMER knob in a clockwise direction until
the ! symbol appears in the display window.
6. Turn the SELECTOR knob to the "0" position.
For example: it is 9:00 a.m., a time of 1 hour and
15 minutes is programmed and the start time is
set to 11:00 a.m. The programme will start
automatically at 11:00 and will end at 12:15.
To cancel a programmed cooking cycle, turn the
PROGRAMMER knob in a clockwise direction until
the 9 symbol appears in the display window.
*
Only available in certain models.
