2.3.5.3 HDMI OUT

(1)RefertothepictureandplugoneconnectoronyourHDMIcabletotheplayer’s

HDMIjack;

(2)RefertothepictureandplugtheotherconnectoronyourHDMIcabletotheTV’s

HDMIjack.

Inthisway,youcanhavethehighestqualityvideoandaudioviaasinglecable.

2.3.6 Digital Audio Device Connection

(1) Refer to the picture and plug in the RCA connector on your coaxial cable to the

player’sS/PDIFCoaxialjack.Orifyouuseopticalfibre,pleaseplugintheToslink

connectoronyouropticalfibretotheplayer’sS/PDIFOpticaljack;(notsupplied)

(2) Refer to the picture and plug in the other connector on your coaxial cable or

optical fibre to the digital audio device. (not supplied)
