LG L1932P-SN [22/23] How to install the vesa standard wall mounting

A21

How to Install the VESA Standard wall mounting

VESA wall mounting

Connected to another object (stand type and wall-

mounted type). This monitor accepts a VESA-

compliant mounting interface pad.- (optional)

For further information, refer to the VESA Wall

Mounting Instruction Guide.

Kensington Security Slot- optional

Connected to a locking

cable that can be purchased

separately at most

computer stores

This monitor meets VESA-compliant mounting interface pad

specifications.
