Connecting the Display

NOTE

‘Self Image Setting Function’? This function provides the user with optimal display settings. When the user

connects the monitor for the first time, this function automatically adjusts the display to optimal settings for individual

input signals. If you want to adjust the monitor while in use, or wish to manually run this function once again, push

the ‘AUTO/SET’ button on the front panel of the monitor. Otherwise, you may execute the ‘ Factory reset’ option on

the OSD adjustment menu. However, be aware that this option initializes all the menu items except ‘Language’.

Using the Computer

1. Place the monitor in a convenient, well-ventilated location near your computer. To adjust

height of your monitor, unlock the stand lock on top of the stand.

2. Connect the signal cable. When attached, tighten the thumbscrews to secure the

connection.

3. Connect the power cord into a proper power outlet

that is easily accessible and close to the display.

Wall-outlet type

PC-outlet type

Power Cord

Signal Cable

Analog signal

D-sub

Digital signal

DVI

Varies according to model.

Mac adapter

For Apple Macintosh use, a separate plug adapter is

needed to change the 15 pin high density (3 row) D-sub

VGA connector on the supplied cable to a 15 pin 2 row

connector.

4. Press button on the front switch panel to turn the power

on. When monitor power is turned on, the 'Self Image

Setting Function' is executed automatically.

(Only Analog Mode)

NOTE

This is a simplified

representation of the rear view.

This rear view represents a

general model; your display

may differ from the view as

shown.

MAC
