A6
Using the Auto Pivot function
Notice
Forte Manager software requires Microsoft Explorer 6.0 or later.
The response time (speed) for the Auto Pivot function can vary depending on the video
card and the PC performance, and these functions are not supported in the DOS mode.
This model supports Auto Pivot (automatic rotation) functions.
To use this function, install the provided Forte Manager software first and then,
perform Automatic setting.(Manual is the default setting when you purchase the product.)
- Refer to the installation guide included in the CD for more details on the installation method.
- For the automatic setting, select Forte Manager -> Option -> Pivot -> Enable AutoPivot.
Auto Pivot
Screen rotation : You can rotate the monitor screen part clockwise by 90
°
.
<When rotated by 90°>
Tilt the screen
part while rotating
it so that the monitor
does not touch
the floor.
※※
Caution : Be careful that your hands are not pressed down when rotating
the screen.
<Pushing the screen
part backwards>
<Rotating clockwise>
This rear view represents a general model, your display may differ from the view as shown.
