LG 21FG6RG-T9 [11/24] Setting up tv stations
![LG 21FG6RG-T9 [11/24] Setting up tv stations](/views2/1085589/page11/bgb.png)
Fine tuning
Normally fine tuning is only necessary if reception is poor.
1. Repeat the 'Manual programme tuning' steps 1 to 3.
2. Press the button to select Fine.
3. Press the button to fine tune for the best picture and sound on
the Fine pull-down menu, then press OK button to store the setting.
4. Press the MENU button to return to normal TV viewing.
5. Change of “ ” from Yellow to red indicates tuning is proper.
Assigning a programme name
1. Repeat the 'Manual programme tuning' steps 1 to 3.
2. Press the button to select Name.
3. Press the button on the Name pull-down menu. You can use a
blank, +, -, the numeric 0 to 9 and the alphabet A to Z.
With the button you can select in the opposite direction.
4. Select the next position by pressing the button and then take your
choice of the second character, then press OK button.
5. Repeat the 'Manual programme tuning' steps 5 to 8.
6. Repeatedly press the MENU to return to normal TV viewing.
Programme
Setting up TV stations
11
POWER
MUTE
1
2
3
4
5
6
8
9
7
0
PSM
SSM
EYE/*
ARC/*
Q.VIEW
LIST
SLEEP
MENU
TV/AV
FAVOURITE
I/II/*
PR
PR
VOL
VOL
OK
MM/*
TURBO
PICTURE/*
