Setting up TV stations
Programme
Up to 200 programmes can be stored by programme
numbers (0 to199). Once you have preset the stations you
will be able to use the or NUMBER buttons to scan the
stations you programmed. Programmes can be tuned using
automatic or manual modes.
Auto programme tuning
All channel that can be received are stored by this method.
It is recommended that you use auto programme during installation of
this set.
1 . Press the MENU button and then button to select the
programme menu
2. Press the button and then button to select Auto
programme.
3. Press the button to display the Auto programme menu.
4. Press the button to select Storage from.
5. Select the beginning programme number with the button or
NUMBER buttons on the Storage from pull-down menu. Any
number under 10 is entered with a numeric '00' in front of it, i.e. '005'
for5.
6. Press the button to select the start.
7. Press the button to begin auto programming. All receivable
stations are stored. To stop auto programming, press the MENU
button.
When auto programming is completed the Programme
edit menu appears on the screen. See the 'Programme edit' section
to edit the stored programme.
8. Press the MENU button to return to normal TV viewing.
Note : In some models up to 100 TV stations can be stored.
Auto Programme
22
9
POWER
MUTE
1
2
3
4
5
6
8
9
7
0
PSM
SSM
EYE/*
ARC/*
Q.VIEW
LIST
SLEEP
MENU
TV/AV
FAVOURITE
I/II/*
PR
PR
VOL
VOL
OK
MM/*
TURBO
PICTURE/*
