On screen language selection (option)
The menu can be displayed on the screen in desired language.
First select your language.
1. Press the MENU button and then button to select the Special
menu.
2. Press the button and then the button to select language
3. Press OK button.
All the On screen displayed will appear in the selected language.
4. Repeatedly press the MENU or Button to return normal TV
viewing.
TV and AV modes (option)
Input can be set to TV or AV mode. AV mode is used when a videocassette
recorder (VCR), or other equipment connected to the set.
Note: When a VCR is connected via the aerial socket; the set is used
in TV mode. See the connection of external equipment’ section.
1. Press the menu button and then button to select the special
menu.
2. Press the button and then button to select Input.
3. Press the button select TV, AV1, AV2 (option).
Note: Avoid giving input at Lout or Rout socket on the back of the set.
To return TV mode, press the or NUMBER button.
Alternatively you can select th TV or AV mode by pressing the TV/AV
button
Child lock
The can be set so that the remote control handset is needed to control. This
feature can be used prevent unauthorized viewing.
1. Press the MENU button and the button to select the special
menu.
2. Press the button and then button to select the child lock.
3. Press the button on the remote control handset to select On.
4. Repeatedly press the MENU or button to return to normal TV
viewing.
With the lock On, the display Child Lock On appears on the screen if any
button on the front panel is pressed while viewing the TV.
Note: The display Child Lock On will not appear on the screen if any
button on the front panel is pressed while displaying the menus.
Other functions
Special
20
POWER
MUTE
1
2
3
4
5
6
8
9
7
0
PSM
SSM
EYE/*
ARC/*
Q.VIEW
LIST
SLEEP
MENU
TV/AV
FAVOURITE
I/II/*
PR
PR
VOL
VOL
OK
MM/*
TURBO
PICTURE/*
