Stomer SCS-185 [6/74] English

Circular saw

INTENDED USE

This tool is intended for lengthways and crossways cutting

of wood with straight cuts as well as angle cuts to 45°; with

the appropriate saw blades also non-ferrous metals, light

building materials and plastics can be cut

TECHNICAL SPECIFICATIONS 1

PRODUCT ELEMENTS 2

1. Handle

2. On/Off switch

3. Cutting depth adjusting lever

4. Lower guard

5. Blade bolt

6. Foot

7. Flange

8. Saw blade

9. Parallel guide

10. Parallel guide knob

11. Cutting angle adjusting knob

12. Laser On/Off switch

13. Spindle-lock button

SAFETY

WARNING! Read all instructions. Failure to follow all

instructions listed below may result in electric shock,

ﬁ re and/or serious injury.

DANGER

● Keep hands away from cutting area and the

blade; keep your second hand on front handle (if

both hands are holding the saw, they can not be cut by

the blade)

● Do not reach underneath the workpiece (the guard

cannot protect you from the blade below the workpiece)

● Adjust the cutting depth to the thickness of the

workpiece (less than a full tooth of the blade teeth

should be visible below the workpiece)

● Never hold piece being cut in your hands or

across your leg (it is important to support the work

properly to minimize body exposure, blade binding, or

loss of control)

● Hold tool by insulated gripping surfaces when

performing an operation where the cutting tool may

contact hidden wiring or its own cord (contact with a

“live” wire will also make exposed metal parts of the tool

“live” and shock the operator)

● When ripping always use a rip fence or straight

edge guide (this improves the accuracy of cut and re-

duces the chance for blade binding)

● Always use blades with correct size and shape of

arbor holes (diamond or round) (blades that do not

match the mounting hardware of the saw will run ec-

centrically, causing loss of control)

● Never use damaged or incorrect blade washers

or bolts (the blade washers and bolt were specially

designed for your saw, for optimum performance and

safety of operation)

English

KICKBACK-CAUSES

● Kickback is a sudden reaction to a pinched, bound or

misaligned saw blade, causing an uncontrolled saw to

lift up and out of the workpiece toward the operator

● When the blade is pinched or bound tightly by the kerf

closing down, the blade stalls and the motor reaction

drives the unit rapidly back toward the operator

● If the blade becomes twisted or misaligned in the cut,

the teeth at the back edge of the blade can dig into the

top surface of the wood causing the blade to climb out

of the kerf and jump back towards operator

KICKBACK - OPERATOR PREVENTION

Kickback is the result of tool misuse and/or incorrect

operating procedures or conditions and can be avoided

by taking proper precautions as given below

● Maintain a ﬁrm grip with both hands on the saw

and position your arms to resist kickback forces;

position your body to either side of the blade, but

not in line with the blade (kickback could cause the

saw to jump backwards, but kickback forces can be

controlled by the operator, if proper precautions are

taken)

● When blade is binding, or when interrupting a cut

for any reason, release the trigger and hold the saw

motionless in the material until the blade comes to

a complete stop; never attempt to remove the saw

from the work or pull the saw backwards while the

blade is in motion or kickback may occur (investigate

and take corrective actions to eliminate the cause of

blade binding; avoid cutting nails or screws)

● When restarting a saw in the workpiece, centre

the saw blade in the kerf and check that saw teeth

are not engaged into the material (if saw blade is

binding, it may walk up or kickback from the workpiece

as the saw is restarted)

● Support large panels to minimize the risk of blade

pinching and kickback (large panels tend to sag under

their own weight; supports must be placed under the

panel on both sides, near the line of cut and near the

edge of the panel)

● Do not use a dull or damaged blade (unsharpened

or improperly set blades produce narrow kerf causing

excessive friction, blade binding and kickback)

● Blade depth and bevel adjusting locking levers

must be tight and secure before making cut (if blade

adjustment shifts while cutting, it may cause binding and

kickback)

● Use extra caution when making a plunge cut into

existing walls or other blind areas (the protruding

blade may cut objects that can cause kickback)

WARNING

● Check lower guard for proper closing before each

use

● Do not operate the saw if lower guard does not

move freely and close instantly

● Never clamp or tie the lower guard into the open

position

● If saw is accidentally dropped, lower guard may be

bent; raise the lower guard with the retracting handle

and make sure it moves freely and does not touch the

blade or any other part, in all angles and depths of cut

Stomer SCS-185 [6/74] English
