● Do not lengthen the spanner, so that you can exercise
more power.
● Do not hit on the spanner with a hammer, for tightening
the shaft.
● The spanner must be removed, after the shaft that has
been tightened.
● Install the saw table and mount the corresponding
screws.
REPLACING THE SAW GUIDE
HAZARD!
● If the saw guide has been damaged, then small pieces
can become jammed between the guide and the saw,
which can block the saw blade. Immediately replace a
defective saw guide.
● Remove the saw guide.
● Remove the defective piece by dislodging it with a
screwdriver.
● Insert a new piece and click it in position.
● Reinstall the saw guide.
MODIFICATIONS
MODIFICATIONS ON THE MITRE AND WIDTH
GUIDE
● Loosen the attachment screws of the guide.
● Adapt the guide so that it is positioned exactly at right
angles to the saw blade, when the mitre table is in the 0°
position.
● Retighten the attachment screws of the guide.
ADAPTING THE SAWING DEPTH STOP
The sawing depth stop limits the depth to which the saw
extends in the saw blade opening.
The saw depth stop must be adapted, if the saw blade
makes contact with the table.
● Loosen the attachment screw of the saw depth stop.
● Adapt the saw depth stop in such a way that the saw
blade extends up to the mitre and depth guide in the saw
blade opening.
● Retighten the attachment screws of the saw depth stop.
● Lower the saw head until it is stopped by the saw depth
stop, and check whether the saw blade can freely rotate
in this position.
CLEANING
Use a brush, a dust cloth or vacuum cleaner, to remove all
wood chips and sawdust from:
– The adjustment facilities
– The operating components
– The motor ventilation openings
– The space under the table gap.
● Set the support arm to 0° (vertical) and tighten the
bevelling lock nut.
● To prevent that the saw blade rotates, pull the saw blade
lock forward. Use your hand at the same time to turn the
saw blade slowly, until the saw blade latch is activated.
● Loosen the driveshaft bolt of the saw (left-turning
thread).
● Remove the shaft bolt and the outer saw fl ange from the
saw shaft.
● Remove the saw blade from the saw shaft and let it down
to remove it from the machine.
● Remove the adapter ring and the inner saw fl ange from
the saw shaft.
● Clean the surfaces of the following components:
– The saw shaft
– The inner saw fl ange
– The saw blade
– The outer saw fl ange
– adapter ring
– The saw blade guard
HAZARD! Do not use any cleaning products (for
instance for removing resin residues) that have
the tendency to cause corrosion on light metals;
this could damage the machine.
● Put the inner saw fl ange and the adapter ring on the saw
shaft.
HAZARD! Be sure to fasten the inner saw fl ange
correctly! The saw may block, or the saw blade
may come lose, if the fl ange is not correctly
fastened.
● Mount the new saw blade and check the rotating direction
(the arrow on the saw blade must point in the same
direction as the arrow on the saw blade guard!).
HAZARD! Only use saw blades that conform to
the applicable standards and that can be used at
the maximum speed indicated in the technical
data sheet.
● DO NOT use:
– Wrong saw blades
– Saw blades made of high-speed steel (HSS)
– Damaged saw blades
– Saw blades with missing teeth
HAZARD!
● Only use OEM components for installing the saw blade.
– Do not use loose reduction rings; the saw blade could
come loose.
– Saw blades must be mounted in such a way that they
cannot wobble, and that they cannot come loose during
operations.
● Install the outer saw fl ange.
● The two fl anges must fi t over the surfaces of the saw
shaft.
● Insert the shaft bolt (left-turning thread) and tighten with
a hexagonal spanner.
HAZARD!
