APPLICATION
The machine is designed for sawing wood. It is not designed
for commercial use.
WARNING! For your own safety, read this manual
and the general safety instructions carefully
before using the appliance. Your power tool
should only be given to other users together with these
instructions.
TECHNICAL DATA (FIG 1)
DESCRIPTION
1. Off push button
2. On push button
3. Mounting holes
4. Metal bar of tilt protector
5. Saw blade
6. Dust bag
7. Saw dust elector
8. Locking screw 1
9. Locking screw 2
10. Spindle lock
11. Caps for carbon brushes
12. Release button of the tool arm
13. Handle
14. Laser unit
15. Retracting blade guard
16. Saw table of the chop and mitre saw
17. Scale for mitre angle
18. Locking knob for various mitre angles
19. Holes for quick-action clamp
20. Vise
21. Vise arm
22. Vise rod
23. Vise knob
24. Clamping screw
25. Fence
26. Lighting unit
27. Light switch
28. Switch for marking of cutting line
29. Clamping lever for various bevel angles
30. Transport safety-lock
31. Extension bar
32. Angle indicator
33. Scale for bevel angle
34. Saw table of the table saw
35. Riving knife
36. Parallel guide
37. Hold-down stick
38. Blade guard
39. Clamping knob of the parallel guide
40. Scale for clearance of the saw blade to the parallel
guide
41. Lower saw blade cover
GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed
warnings and follow instructions may result in electric
shock, fi re and/or serious injury. Keep safety warnings and
instructions for future reference. The term "power tool" in
the safety warnings refers to your mainsoperated (corded)
power tool or battery-operated (cordless) power tool.
WORKING AREA
● Keep working area clean and well lit. Untidy and dark
areas can lead to accidents.
● Do not operate power tools in potentially explosive
surroundings, for example, in the presence of infl ammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
● Keep children and bystanders at a distance when
operating a power tool. Distractions can cause you to
lose control of it.
ELECTRICAL SAFETY
Always check that the power supply corresponds
to the voltage on the rating plate.
● Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use adapter plugs with earthed
power tools. Unmodifi ed plugs and matching outlets will
reduce the risk of a lethal electric shock.
● Avoid body contact with earthed surfaces such as pipes,
radiators, kitchen ranges and refrigerators. There is an
increased risk of a lethal electric shock if your body is
earthed.
● Do not expose power tools to rain or wet conditions. If
water gets inside a power tool, it will increase the risk of
a lethal electric shock.
● Do not damage the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep the cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of a lethal electric
shock.
● When operating a power tool outdoors, use an extension
cable suitable for outdoor use. Using a cord suitable for
outdoor use reduces the risk of a lethal electric shock.
● If operating a power tool in a damp location is
unavoidable, use a power supply protected by a residual
current device (RCD). Using an RCD reduces the risk of
a lethal electric shock.
PERSONAL SAFETY
● Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool when you are tired or under the infl uence of drugs,
alcohol or medication. A moment of inattention when
operating a power tool may result in serious personal
injury.
● Use safety equipment. Always wear eye protection.
Using safety equipment such as a dust mask, non-skid
safety shoes, a hard hat, or hearing protection whenever
it is needed will reduce the risk of personal injury.
● Avoid accidental starts. Ensure the switch is in the off
position before inserting the plug. Carrying power tools
with your fi nger on the switch or plugging in power tools
when the switch is in the on position makes accidents
more likely.
