12 | English
1 609 929 V16 | (12.7.11) Bosch Power Tools
11 Dust bag
12 Folded filter
13 Motor protection filter
14 Level sensors
Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
Technical Data
Noise Information
Measured values determined according to EN 60704.
Typically the A-weighted sound pressure level of the product
is less than 70 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical data” is in conformity with the fol-
lowing standards or standardization documents: EN 60335
and the directives 2006/42/EC, 2004/108/EC including
their amendments.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
27.05.2011
Assembly
f Before any work on the vacuum cleaner itself, pull the
mains plug.
Replacing/Inserting the Dust Bag (see figure A)
– Unlock the latches 10 and remove the vacuum lid 3.
– Pull off the full dust bag 11 from the connection flange to-
ward the rear. Close the opening of the dust bag by folding
down the lid. Remove the closed dust bag from the vacuum
cleaner.
– Slide the new dust bag 11 over the connection flange of the
vacuum cleaner. Make sure that the full length of the dust
bag 11 faces against the inner wall of the container 9. Reat-
tach the vacuum lid 3.
– Lock the latches 10.
For dry vacuuming operation, a dust bag 11 should be insert-
ed. When operating with a dust bag 11, the folded filter 12
clogs slower, the vacuuming performance is kept up longer
and the disposal of dust becomes easier.
Mounting the Vacuum Hose (see figure A)
Mount the vacuum hose 8 onto the hose connection piece 7
and turn it in clockwise direction to the stop.
Insert the extension tubes firmly into each other.
Note: Bosch recommends using static-discharging hoses
with a hose Ø of 19 or 35 mm.
Operation
Starting Operation
f Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the vacuum cleaner. Equipment marked
with 230 V can also be operated with 220 V.
f Switch the vacuum cleaner off immediately as soon as
foam or water comes out, and empty the container.
Otherwise, the vacuum cleaner can become damaged.
Symbols on the Mode Selector Switch
Switching On and Off
To start the operation of the vac, set the mode selector
switch 4 to on.
To switch off the vac, set the mode selector switch 4 to off.
All-Purpose Vacuum Cleaner GAS 25
Professional
Article number 0 601 979 1..
Rated power input
W1200
Frequency
Hz 50/60
Container volume (gross)
l25
Net volume
l16
Dust bag contents
l9
Vacuum, max.*
hPa 248
Airflow, max.*
m
3
/h 220
Suction capacity
W 316 (6 mbar)
Surface of folded filter
cm
2
4300
Weight according to
EPTA-Procedure 01/2003
kg 11.8
Protection class
/I
Degree of protection
IP 24
* measured at the blower
The values given are valid for nominal voltages [U] of 230 V. For lower
voltage and models for specific countries, these values can vary.
Please observe the article number on the type plate of your vacuum
cleaner. The trade names of the individual vacuum cleaners may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
on Switching On
off Switching Off
Electromagnetic filter cleaning
Operation with remote automatic switching
OBJ_BUCH-464-005.book Page 12 Tuesday, July 12, 2011 9:40 AM
