ENGLISHen

5Toothed rod

6 Rod knob

7 Trigger switch for switching the device on and

off

8 Adjusting wheel for setting feed rate

9 Battery pack release button

10 Battery pack

11 Plastic bag *

12 Screw

13 Extruder plate for plastic bags

14 Extrusion plate for cartridges

15 Cartridge *

* not included in scope of delivery

6.1 Battery pack

Charge the battery pack before use.

If performance diminishes, recharge the battery

pack.

The ideal storage temperature is between 10°C and

30°C.

To remove the battery pack: Press the battery

pack release button (9) and remove the battery (10)

pack.

To fit the battery pack: Slide in the battery pack

(10) until it engages .

6.2 Fitting plastic bags

Attach the extruder plate for plastic bags

(13) as illustrated. (To do this, (3) unscrew

the tube and then refasten it securely). See page 2,

fig. A.

- Unscrew the front cap (1) from the tube (3).

- Snip the top of the nozzle (2) as required for the

work to be carried out.

- Insert the plastic bag in the tube (3) (thus pushing

back the toothed rod (5)).

- Trim the plastic bag (11) as recommended by the

plastic bag manufacturer.

- Insert the nozzle in the front cap (2) and secure the

front cap (1) tightly.

- Now gently press the rod knob (6) to advance the

toothed rod until it comes in contact with the

plastic bag.

6.3 Fitting the cartridge

Remove the extruder plate for plastic bags

(13) as illustrated. (To do this, (3) unscrew

the tube and then refasten it securely). See page 2,

fig. B.

- Unscrew the front cap (1) from the tube (3).

- Open the cartridge (15) as per the cartridge manu-

facturer's instructions.

- Snip the top of the cartridge nozzle as required for

the work to be carried out.

- Now insert the cartridge (15), with the attached

cartridge nozzle, into the tube (3) (thus pushing

back the rod (5)).

- Screw on the front cap (1) tightly.

- Now gently press the rod knob (6) to advance the

toothed rod until it comes in contact with the

cartridge.

7.1

Multifunctional monitoring system

If the device switches off automatically, the

machine electronics have activated automatic

protection mode.

Causes and remedies:

1. Battery pack almost flat (the electronics

prevent the battery pack from discharging totally

and avoid irreparable damage).

If the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the temperature cut-out.

Leave the machine or battery pack to cool.

3. If the current is too high (for example, during

extended periods of overloading) the device is

switched off.

Using the trigger switch, turn off the device (7)

and remove the battery pack. Determine the

cause of the problem and resolve it.

7.2 Setting the feed rate

Set the feed rate using the adjusting wheel (8).

7.3 Switching on and off

Switching on: press the trigger switch (7).

Switching off: release the trigger switch (7). Note:

The toothed rod is automatically retracted slightly to

avoid dripping.

However, if you activate the trigger switch at brief

intervals (shorter than 1 second), the rod is not auto-

matically retracted. This allows precise dosage of

volumes.

Note:

The motor switches off automatically if either

the cartridge or the plastic bag is empty.

Use only genuine Metabo accessories.

Conversion kit 400 ml Order no.: 6.30148

Comprising a short toothed rod (5) and 400 ml tube

(3) for replacing parts.

See page 2, fig. C.

- Unscrew the tube (3).

- Extract the screw from the rod knob (6) and pull

the rod knob back from (6) the rod (5).

- Pull the toothed rod forwards from the motor

housing.

- Extract the screw and dismantle the components

(12) to (14) from the rod.

- Insert the rod from the conversion kit towards the

front.

6. Initial Operation

7. Use

8. Accessories
