Hitachi DV14DSL-TL [12/98] English

Hitachi DV14DSL-TL [12/98] English
English
11
(2)
Replacing the hook and tightening the screws.
Install securely the hook in the groove of power tool
and tighten the screws to fix the hook firmly. (Fig. 10)
8. About Remaining Battery Indicator
When pressing the remaining battery indicator switch,
the remaining battery indicator lamp lights and the
battery remaining power can be checked. (Fig.11)
When releasing your finger from the remaining
battery indicator switch, the remaining battery
indicator lamp goes off. The table 6 shows the state
of remaining battery indicator lamp and the battery
remaining power.
As the remaining battery indicator shows somewhat
differently depending on ambient temperature and
battery characteristics, read it as a reference.
6. How to select tightening torque and rotational speed
Table 5
Use
Clutch Position
Rotating speed selection (Position of the shift knob)
LOW (Low speed) HIGH (High speed)
Machine
1 – 22
For 4 mm or smaller diameter For 6 mm or smaller
Driving
screw screws. diameter screws.
Wood screw 1 –
For 6.8 mm or smaller nominal For 3.8 mm or smaller
diameter screws. nominal diameter screws.
Brick
For 13 mm or smaller For 10 mm or smaller
diameters. diameters.
Wood
For 36 mm or smaller For 18 mm or smaller
Drilling
diameters. diameters.
Metal
For drilling with a metal
–––––––––––––––
working drill bit.
CAUTION:
The selection examples shown in Table 5 should be
considered as general standard. As different types of
tightening screws and different materials to be
tightened are used in actual works proper adjustments
are naturally necessary.
When using the impact driver drill with a machine
screw at HIGH (high speed), a screw may damage or
a bit may loose due to the tightning torque is too
strong. Use the driver drill at LOW (low speed) when
using a machine screw.
NOTE:
The use of the Li-ion battery in a cold condition
(below 0 degree Centigrade) can sometimes result in
the weakened tightening torque and reduced amount
of work. This, however, is a temporary phenomenon,
and returns to normal when the battery warms up.
7. Using the hook
The hook is used to hang up the power tool to your
waist belt while working.
CAUTION:
When using the hook, hang up the power tool firmly
not to drop accidentally.
If the power tool is dropped, it may lead to an accident.
When carrying the power tool with hooked to your
waist belt, do not fit any bit to the tip of power tool. If
the sharp bit such as drill is fitted to the power tool
when carrying it with hooked to your waist belt, you
will be injured.
Install securely the hook. Unless the hook is securely
installed, it may cause an injury while using.
(1) Removing the hook.
Remove the screws fixing the hook with Philips screw
driver. (Fig. 9)
Table 6
State of lamp Battery Remaining Power
The battery remaining power
is enough.
The battery remaining power
is a half.
The battery remaining power
is nearly empty.
Re-charge the battery soonest
possible.
Table 4
Work Suggestions
Brick
Wood
Drilling
Steel
Use for drilling purpose.
Aluminum
Machine screw Use the bit or socket matching the screw diameter.
Driving
Wood screw Use after drilling a pilot hole.
