ENGLISH
8
(Original instructions)
Electrical safety
This tool is double insulated;
therefore no earth wire is required.
Always check that the power supply
corresponds to the voltage on the
rating plate.
• If the supply cord is damaged, it must be
replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
Features
1. On/o switch
2. Lock-o button
3. Main handle
4. Secondary handle
5. Spindle lock button
6. Shoe
7. Saw blade
8. Saw blade guard
9. Guard handle
10. Saw dust outlet
Assembly
Warning! Before attempting any of the
following operations, make sure that the
tool is switched o and unplugged and that
the saw blade has stopped.
Removing and fitting a saw blade
(fig. A)
Removing
• Keep the spindle lock button (5)
depressed and rotate the blade until the
spindle lock engages.
• Loosen and remove the blade retaining
screw (11) by turning it counterclockwise
using the spanner (12) supplied.
• Remove the outer washer (13).
• Remove the saw blade (7).
Fitting
• Place the saw blade onto the inner flange
(14), making sure that the arrow on the
blade points in the same direction as the
arrow on the tool.
• Fit the outer washer (13) on the spindle,
with the raised part pointing away from
the saw blade.
• Insert the blade retaining screw (11) into
the hole.
• Keep the spindle lock button (5)
depressed.
• Securely tighten the blade retaining
screw by turning it clockwise using the
spanner (12) supplied.
• Adjust the riving knife as described
below.
Fitting and removing the parallel
fence (fig. B)
• The parallel fence is used to saw in a
straight line parellel to the edge of the
workpiece.
Fitting
• Loosen the locking knob (16).
• Insert the parallel fence (17) through the
openings (18).
• Slide the parallel fence into the desired
position.
• Tighten the locking knob.
Removing
• Loosen the locking knob.
• Pull the parallel fence off the tool.
Use
Warning! Let the tool work at its own pace.
Do not overload.
Note: This tool can be used in the right hand
or the left hand.
Adjusting the sawing angle (fig. C)
The default angle between the saw blade
and the shoe is 90°.
