12 ENGLISH
Overheat protection
When the tool is overheated, the tool stops automati-
this situation, let the tool cool before turning the tool on
again.
On
Blinking
tool again.
Overdischarge protection
Releasing protection lock
state.
In this situation, the tool does not start even if turning
On
Off
Blinking
Shaft lock
Press the shaft lock to prevent spindle rotation when
installing or removing accessories.
1
1. Shaft lock
NOTICE: Never actuate the shaft lock when the
spindle is moving.
Switch action
CAUTION: Before installing the battery car-
tridge into the tool, always check to see that the
slide switch actuates properly and returns to the
"OFF" position when the rear of the slide switch
is depressed.
CAUTION: Switch can be locked in "ON" posi-
tion for ease of operator comfort during extended
use. Apply caution when locking tool in "ON"
For continuous operation, press the front of the slide
switch to lock it.
1
1. Slide switch
Speed adjusting dial
-
ber on the dial and the corresponding rotation speed.
1
1.
Number Speed
1 3,000 min
-1
2 4,500 min
-1
3 6,000 min
-1
4 7,500 min
-1
5 8,500 min
-1
