15 ENGLISH
1
2
1. Lock nut wrench 2. Shaft lock
in reverse.
Optional accessory
WARNING: Always use supplied guard when
Wheel can shatter during use
1
2
3
4
1. Lock nut 2. Flex wheel 3. Back up pad 4. Inner
Follow instructions for depressed center wheel but also
accessories page in this manual.
Installing or removing abrasive disc
Optional accessory
NOTE:-
1
2
3
4
1. Sanding lock nut 2.3. Rubber pad
4.
1.
2. Mount the rubber pad onto the spindle.
3. Fit the disc on the rubber pad and screw the sand-
ing lock nut onto the spindle.
4.
tighten the sanding lock nut clockwise with the lock nut
wrench.
reverse.
model
1
2
3
1. Sanding lock nut 2.3. Rubber pad
1. Mount the rubber pad onto the spindle.
2. Fit the disc on the rubber pad and screw the sand-
ing lock nut onto the spindle.
3.
tighten the sanding lock nut clockwise with the lock nut
wrench.
reverse.
