13
INSTALLATION
Bench mounting
Fig.1
When the tool is shipped, the handle is locked in the
lowered position by the stopper pin. Release the stopper
pin by simultaneously applying a slight downward
pressure on the handle and pulling the stopper pin.
WARNING:
Ensure that the tool will not move on the
supporting surface. Movement of the miter saw
on the supporting surface while cutting may result
in loss of control and serious personal injury.
Fig.2
This tool should be bolted with four bolts to a level and
stable surface using the bolt holes provided in the tool's
base. This will help prevent tipping and possible injury.
FUNCTIONAL DESCRIPTION
WARNING:
Always be sure that the tool is switched off and
unplugged before adjusting or checking
function on the tool. Failure to switch off and
unplug the tool may result in serious personal
injury from accidental start-up.
Blade guard
Fig.3
When lowering the handle, the blade guard rises
automatically. The blade guard returns to its original
position when the cut is completed and the handle is
raised.
WARNING:
Never defeat or remove the blade guard or the
spring which attaches to the guard. An exposed
blade as a result of defeated guarding may result
in serious personal injury during operation.
In the interest of your personal safety, always maintain the
blade guard in good condition. Any irregular operation of
the blade guard should be corrected immediately. Check
to assure spring loaded return action of guard.
WARNING:
Never use the tool if the blade guard or spring
are damaged, faulty or removed. Operation of
the tool with a damaged, faulty or removed guard
may result in serious personal injury.
If the see-through blade guard becomes dirty, or sawdust
adheres to it in such a way that the blade and/or workpiece
is no longer easily visible, unplug the saw and clean the
guard carefully with a damp cloth. Do not use solvents or
any petroleum-based cleaners on the plastic guard
because this may cause damage to the guard.
If the blade guard becomes dirty and needs to be
cleaned for proper operation follow the steps below:
With the tool switched off and unplugged, use the
supplied socket wrench to loosen the hex bolt holding
the center cover. Loosen the hex bolt by turning it
counterclockwise and raise the blade guard and center
cover.
Fig.4
With the blade guard so positioned, cleaning can be
more completely and efficiently accomplished. When
cleaning is complete reverse procedure above and
secure bolt. Do not remove spring holding blade guard.
If guard becomes damaged through age or UV light
exposure, contact a Makita service center for a new
guard. DO NOT DEFEAT OR REMOVE GUARD.
Positioning kerf board
Fig.5
Fig.6
This tool is provided with the kerf boards in the turn base
to minimize tearing on the exit side of a cut. The kerf
boards are factory adjusted so that the saw blade does
not contact the kerf boards. Before use, adjust the kerf
boards as follows:
Fig.7
First, unplug the tool. Loosen all the screws (2 each on left
and right) securing the kerf boards. Re-tighten them only
to the extent that the kerf boards can still be easily moved
by hand. Lower the handle fully and push in the stopper
pin to lock the handle in the lowered position. Loosen the
locking screw counterclockwise which secures the upper
slide poles and also push forward the lock lever which
secures the lower slide poles. Pull the carriage toward you
fully. Adjust the kerf boards so that the kerf boards just
contact the sides of the blade teeth. Tighten the front
screws (do not tighten firmly). Push the carriage toward
the guide fence fully and adjust the kerf boards so that the
kerf boards just contact the sides of blade teeth. Tighten
the rear screws (do not tighten firmly).
After adjusting the kerf boards, release the stopper pin
and raise the handle. Then tighten all the screws
securely.
NOTICE:
After setting the bevel angle ensure that the kerf
boards are adjusted properly.
Correct adjustment
of the kerf boards will help provide proper support of
the workpiece minimizing workpiece tear out.
Maintaining maximum cutting capacity
This tool is factory adjusted to provide the maximum
cutting capacity for a 260 mm saw blade.
Unplug the tool before any adjustment is attempted.
When installing a new blade, always check the lower
limit position of the blade and if necessary, adjust it as
follows:
