Guide fence (SLIDING FENCES which are

upper and lower fences) adjustment

WARNING:

• Before operating the tool, make sure that the upper

and lower fences are secured firmly.

• Before bevel-cutting, make sure that no part of

the tool, especially the blade, contacts the

upper and lower fences when fully lowering

and raising the handle in any position and

while moving the carriage through its full range

of travel. If the tool or blade makes contact with

the fence this may result in kickback or unexpected

movement of the material and serious personal

injury.

Fig.41

The lower fences can be moved inward and outward by

loosening the clamping screws.

Fig.42

A red indicating area will appear as the lower fences are

moved inward and will disappear as the lower fences are

moved outward.

The upper fences can be removed or moved inward and

outward by loosening the levers.

Fig.43

In case of bevel-cutting, adjust the lower and upper

fence positions to be as close to the blade as practical to

provide maximum workpiece support, and make sure

that no part of the tool, especially the blade, contacts the

lower and upper fences when lowering and raising the

handle fully at any position and pulling or pushing the

carriage all the way at the lowest position.

Before cutting operations, make a dry run with the saw

turned off and unplugged, then check clearance

between fences and moving parts.

Before cutting operations, firmly secure lower fences by

tightening the clamping screws and upper fences by

tightening the levers.

When bevel-cutting operations are complete, don't

forget to return the upper fences to the original position

and return it.

Vertical vise

Fig.44

The vertical vise can be installed in two positions on

either the left or right side of the base. Insert the vise rod

into the hole in the base.

Position the vise arm according to the thickness and

shape of the workpiece and secure the vise arm by

tightening the screw. If the screw to secure the vise arm

contacts the carriage, install the screw on the opposite

side of vise arm. Make sure that no part of the tool

contacts the vise when lowering the handle fully and

pulling or pushing the carriage all the way. If some part

contacts the vise, re-position the vise.

Press the workpiece flat against the guide fence and the

turn base. Position the workpiece at the desired cutting

position and secure it firmly by tightening the vise knob.

Turning the vise knob to 90° counterclockwise allows the

vise knob to be moved up and down, facilitating the

quick setting of workpiece. To secure the workpiece after

setting, turn the vise knob clockwise.

WARNING:

• The workpiece must be secured firmly against

the turn base and guide fence with the vise

during all operations. If the workpiece is not

properly secured against the fence the material

may move during the cutting operation causing

possible damage to the blade, causing the material

to be thrown and loss of control resulting in serious

personal injury.

Horizontal vise (optional accessory)

Fig.45

The horizontal vise can be installed in two positions on

either the left or right side of the base.

Fig.46

When performing 15° or greater miter cuts, install the

horizontal vise on the side opposite the direction in

which the turn base is to be turned.

By flipping the vise nut counterclockwise, the vise is

released, and rapidly moves in and out. To grip the

workpiece, push the vise knob forward until the vise

plate contacts the workpiece and flip the vise nut

clockwise. Then turn the vise knob clockwise to secure

the workpiece.

The maximum width of workpiece which can be secured

by the horizontal vise is 215 mm.

WARNING:

•

Always rotate the vise nut clockwise until the

workpiece is properly secured.

If the workpiece is

not properly secured the material may move during

the cutting operation causing possible damage to

the blade, causing the material to be thrown and loss

of control resulting in serious personal injury.

•

When cutting a thin workpiece, such as base boards,

against the fence, always use the horizontal vise.

Holders (Optional accessory)

Fig.47

The holders can be installed on either side as a

convenient means of holding workpieces horizontally.

Slip the holder rods into the holes in the base and adjust

their length according to the workpiece to be held. Then

tighten the holders securely with the screws.

WARNING:

• Always support a long workpiece so it is level

with the top surface of the turn base for an

accurate cut and to prevent dangerous loss of

tool control. Proper workpiece support will help
