Carrying tool

Fig.59

Make sure that the tool is unplugged. Secure the blade

at 0° bevel angle and the turn base at the full right miter

angle position. Secure the slide poles so that the lower

slide pole is locked in the position of the carriage fully

pulled to operator and the upper poles are locked in the

position of the carriage fully pushed forward to the guide

fence (refer to the section titled "Slide lock adjustment ".)

Lower the handle fully and lock it in the lowered position

by pushing in the stopper pin.

Carry the tool by holding both sides of the tool base as

shown in the figure. If you remove the holders, dust bag,

etc., you can carry the tool more easily.

Fig.60

WARNING:

• Stopper pin is only for carrying and storage

purposes and should never be used for any

cutting operations. The use of the stopper pin for

cutting operations may cause unexpected

movement of the saw blade resulting in kickback

and serious personal injury.

CAUTION:

• Always secure all moving portions before carrying

the tool. If portions of the tool move or slide while

being carried loss of control or balance may occur

resulting in personal injury.

MAINTENANCE

WARNING:

•

Always be sure that the tool is switched off and

unplugged before attempting to perform

inspection or maintenance.

Failure to unplug and

switch off the tool may result in accidental start up of

the tool which may result in serious personal injury.

•

Always be sure that the blade is sharp and clean

for the best and safest performance.

Attempting a

cut with a dull and /or dirty blade may cause

kickback and result in a serious personal injury.

NOTICE:

• Never use gasoline, benzine, thinner, alcohol or

the like. Discoloration, deformation or cracks may

result.

Adjusting the cutting angle

This tool is carefully adjusted and aligned at the factory,

but rough handling may have affected the alignment. If

your tool is not aligned properly, perform the following:

1. Miter angle

Push the carriage toward the guide fence and

tighten the locking screw clockwise and pull the

lock lever towards the front of the saw to secure

the carriage.

Turn the grip counterclockwise which secures the

turn base. Turn the turn base so that the pointer

points to 0° on the miter scale. Then turn the turn

base slightly clockwise and counterclockwise to

seat the turn base in the 0° miter notch. (Leave as

it is if the pointer does not point to 0°.) Loosen the

hex sockets bolts securing the guide fence using

the socket wrench.

Fig.61

Lower the handle fully and lock it in the lowered

position by pushing in the stopper pin. Square the

side of the blade with the face of the guide fence

using a triangular rule, try-square, etc. Then

securely tighten the hex socket bolts on the guide

fence in order starting from the right side.

Fig.62

Make sure that the pointer points to 0° on the miter

scale. If the pointer does not point to 0°, loosen the

screw which secures the pointer and adjust the

pointer so that it will point to 0°.

2. Bevel angle

Push the latch lever forward fully to release the positive

stops.

(1) 0° bevel angle

Fig.63

Push the carriage toward the guide fence and

tighten the locking screw clockwise and pull

the lock lever towards the front of the saw to

secure the carriage. Lower the handle fully and

lock it in the lowered position by pushing in the

stopper pin. Loosen the lever at the rear of the

tool.

Fig.64

Turn the hex socket bolt on the right side of

the arm holder two or three revolutions

counterclockwise to tilt the blade to the right.

Fig.65

Carefully square the side of the blade with

the top surface of the turn base using the

triangular rule, try-square, etc. by turning the

hex socket bolt on the right side of the arm

holder clockwise. Then tighten the lever

securely.

Fig.66

Make sure that the pointers on the arm holder

point to 0° on the bevel scale plate on the

arm. If they do not point to 0°, loosen the

screws which secure the pointers and adjust

them so that they will point to 0°.

(2) 45° bevel angle

Fig.67

Adjust the 45° bevel angle only after

performing 0° bevel angle adjustment. To

adjust left 45° bevel angle, loosen the lever

and tilt the blade to the left fully. Make sure

that the pointer on the arm holder points to
