Bosch GSA 18 V-LI C (06016A5001) без акк. и з.у [14/199] Intended use
14 | English
1 619 P13 233 | (5.8.15) Bosch Power Tools
Product Description and
Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for sawing wood, plastic, metal and
building materials while resting firmly on the workpiece. It is
suitable for straight and curved cuts. The saw blade recom-
mendations must be observed.
The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Saw blade*
2 Base plate
3 Locking sleeve for saw blade
4 Stroke rod
5 Battery pack
6 Lock-off button for On/Off switch
7 On/Off switch
8 “PowerLight”
9 Handle (insulated gripping surface)
10 Battery unlocking button
11 Battery charge-control indicator
12 Saw blade holder
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Sound emission values determined according to
EN 60745-2-11.
Typically the A-weighted noise levels of the product are:
Sound pressure level 82 dB(A); Sound power level 93 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2009/125/EC (Regulation
1194/2012), 2011/65/EU, until 19 April 2016:
2004/108/EC, from 20 April 2016 on: 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-11.
Sabre saw GSA 18 V-LI C
Article number
3 601 FA5 0..
Rated voltage
V= 18
Stroke rate at no load n
0
min
-1
0–3050
Tool holder
SDS
Stroke
mm 21
Cutting depth, max.
– in wood
– in non-alloy steel
– Pipe diameter
mm
mm
mm
200
16
100
Weight according to
EPTA-Procedure 01/2003
kg 2.3
* Limited performance at temperatures <0 °C
Technical data determined with battery from delivery scope.
Permitted ambient temperature
–during charging
– during operation* and during
storage
°C
°C
0...+45
–20...+50
Recommended batteries
GBA 18 V...
GBA 18 V...W
Recommended chargers
AL 18..
GAL 3680
GAL 18...W
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745-2-11:
Cutting board: a
h
=9m/s
2
, K=1,5 m/s
2
,
Cutting wooden beam: a
h
=8m/s
2
, K=1,5 m/s
2
.
The values given for sawing particle board apply for a workpiece thick-
ness of 20 mm.
Sabre saw GSA 18 V-LI C
* Limited performance at temperatures <0 °C
Technical data determined with battery from delivery scope.
OBJ_BUCH-2489-002.book Page 14 Wednesday, August 5, 2015 12:32 PM
