11 ENGLISH

Installing or removing depressed

center wheel or ap disc

Optional accessory

WARNING: When using a depressed center

wheel or ap disc, the wheel guard must be tted

on the tool so that the closed side of the guard

always points toward the operator.

CAUTION: Make sure that the mounting part

of the inner ange ts into the inner diameter of

the depressed center wheel / ap disc perfectly.

Mounting the inner ange on the wrong side may

result in the dangerous vibration.

Mount the inner ange onto the spindle.

Make sure to t the dented part of the inner ange onto

the straight part at the bottom of the spindle.

Fit the depressed center wheel / ap disc on the inner

ange and screw the lock nut onto the spindle.

► 1. Lock nut 2. Depressed center wheel 3. Inner

ange 4. Mounting part

To tighten the lock nut, press the shaft lock rmly so

that the spindle cannot revolve, then use the lock nut

wrench and securely tighten clockwise.

► 1. Lock nut wrench 2. Shaft lock

To remove the wheel, follow the installation procedure

in reverse.

Installing or removing ex wheel

Optional accessory

WARNING: Always use supplied guard when

ex wheel is on tool. Wheel can shatter during use

and guard helps to reduce chances of personal injury.

► 1. Lock nut 2. Flex wheel 3. Back up pad 4. Inner

ange

Follow instructions for depressed center wheel but also

use back up pad over wheel. See order of assembly on

accessories page in this manual.

Installing or removing abrasive disc

Optional accessory

NOTE: Use sander accessories specied in this man-

ual. These must be purchased separately.

For 100 mm (4″) model

► 1. Sanding lock nut 2. Abrasive disc 3. Rubber pad

4. Inner ange

1. Mount the inner ange onto the spindle.

2. Mount the rubber pad onto the spindle.

3. Fit the disc on the rubber pad and screw the sand-

ing lock nut onto the spindle.

4. Hold the spindle with the shaft lock, and securely

tighten the sanding lock nut clockwise with the lock nut

wrench.

To remove the disc, follow the installation procedure in

reverse.
