8
Function Buttons
①②
③
④
⑤
⑥
①
Power
Button
②
Setting Button.
Short press to enter the clock setting
and
long press to enter the alarm clock setting. Short
press to enter the next setting after entering the setting
mode, and
long press to exit the setting mode. (In the
standby mode, you cannot enter the setting mode. If
you need to set it, please wake up and then make the
relevant settings.)
Increase the screen brightness. In the setting mode,
increase the clock/alarm setting value and select the
alarm on/off.
Decrease the screen brightness. In the setting mode,
decrease the clock/alarm setting value and select the
alarm on/off.
Switch the Celsius/Fahrenheit of the regular
temperature.
Charging power connector (maximum input DC5V 2A)
③
④
⑤
⑥
