3
Main LCD Display
Instrument Overview
⑩
⑪
⑫
⑬
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑭
⑮
⑯
⑰
①
Main display
②
Auto
standby
③
AUTO
Auto range
④
MANU
Manual range
⑤
Diode
test
⑥
REL
Relative
value test
