Zotek ZT-M1 [10/31] Readings push again to exit the relative
![Zotek ZT-M1 [10/31] Readings push again to exit the relative](/views2/1893230/page10/bga.png)
③
Push
this button once to enter the
manual
range
mode. In manual range mode,
each
push
increases the range; when the
highest
range
is reached, the next push will lead
to
the
lowest range. To exit the manual
range
mode,
Long push for exit.
④
Push this button once to enter the V.F.C
model. Push once more to exit the model.
⑤
Push
this button to enter the relative
mode.
The
product will store the present
reading
as
a reference for subsequent
readings.
The
display is zeroed, and the
stored
reading
is subtracted from all
subsequent
readings
. Push again to exit the
relative
mode
.
Push
this button over 2 seconds, it
will
open
the flashlight, long push again
to
turn
off the flashlight
⑥
Push
to toggle between the MAX and
the
MIN
mode. To exit MAX/MIN mode,
push
the
button for more than 2 seconds
6
