Zotek ZT-M1 [12/31] Frequency equal to
![Zotek ZT-M1 [12/31] Frequency equal to](/views2/1893230/page12/bgc.png)
8
AC V≤750V,
Frequency
V.F.C
DC V
≤1000V
AC V
（mV）≤800.0mV
Frequency (Equal to
)
DC V
（mV）≤800.0mV
Frequency
，Duty cycle：1%~99%。
Resistance
：≤80MΩ。
Capacitance
：≤100mF。
Diode
Continuity
DC A
：≤20A。
AC A
：≤20A。
DC A
：≤800.0mA。
AC A
：≤800.0mA。
DC A
：≤800.0μA。
AC A
：≤800.0μA。
Celsius:
-20~1000, Fahrenheit:-
4~1832
