③
Push
once to hold the current reading on
the
display
; push again to continue
normal
operation
. Long press more than 2s to turn
on
backlight,
long press again to turn off it.
④
Press
this button to enter in DC
voltage
function,
press it to switch in DC and
AC
voltage
. When test AC voltage, vice
display
will
show frequency. When test DC
voltage,
vice
display will show regular temperature
.
Long
press temperature button to switch
in
Celsius
and Fahrenheit.
⑤
Push
this button to toggle between
testing
modes
of Resistance, Diode/Continuity,
and
Capacitance
. Vice display will show
regular
temperature
, now long press
temperature
button
to switch in Celsius and Fahrenheit .
⑥
Short
press to enter in NCV test function,
then
press
again to turn it off. Long press to
switch
temperature
unit in ℃/℉.
6
