Measurements Instruction
Measure AC/DC Voltage
1. Press the button to enter voltage test, short
press to choose AC or DC Voltage range. Now, vice
display will show frequency when on AC mode; vice
display will show regular temperature when on DC mode.
2. Touch the probes to the correct test points of the circuit
to measure the voltage.
3. Read the measured voltage on the display.
Measure Resistance
1.Press button once to switch to resistance
range.
2. Use the probe pin to contact two sides of the
resistance.
3. Read the measured resistance on the display.
7
• Do not measure voltage that exceeds the extremes
as indicated in the Specifications.
• Do not touch high voltage circuit during
measurements.
