Zotek VC921 [8/22] Test unit
![Zotek VC921 [8/22] Test unit](/views2/1893257/page8/bg8.png)
4
⑧
Duty cycle
⑨
Capacitance
test (Farad)
⑩
Voltage
test（volt）
⑪
Resistance test (ohm)
⑫
Data
hold
⑬
Display shows maximum
reading
⑭
Display shows minimum
reading
⑮
Continuity test
⑯
Diode test
⑰
Display shows minimum reading.
⑱
MANU
Manual
range
⑲
Auto
test
Test unit
⑦
Frequency test. (Hertz)
