OIMM – VENTUS PRO
Air handling units are supplied with locked access doors as an option. So, unauthorized persons are not permitted
to enter the sections which represent a danger. The most important potential dangers for life and health are
described below. The units are manufactured in conformity with machinery normative 98/37/EC. If the user
thinks to take further measures to restrict every possible remaining danger, he will be able to recognize them by
the general description below.
This publication explains the proper use and installation of centrifugal fans in order to warn operating and
maintenance personnel of the commonly recognized dangers associated with this equipment.
In addition to follow the manufacturer’s installation instructions, care must be taken to ensure compliance with
federal, state and local rules, regulations and standards.
Centrifugal fans in air handling units are located inside a casing, so accessibility to the fan is occasional or
infrequent. For this reason, protective devices are offered as optional accessories only at specic user’s request.
However as in case with other machinery involving moving parts, common sense and caution will preserve
personnel safety.
The available optional guarding devices are:
• fan inlet and outlet guards: Centrifugal fans in air handling units are usually connected directly to ductwork
which will prevent the contact with the internal moving parts. In case there is an exposed inlet or outlet
which could represent a danger, suitable guards can be installed,
• drive guards: Safety guards should be used when drive systems are accessible by the personnel,
• limit switch: Cuts off the power supply of the fan motor when door opens. As the fan keeps on rotating, do
not attempt to enter the unit within minimum 2minutes, after opening the door.
Also, lockout switches and suitable warnings should be used. Maintenance personnel should engage the lockout
switch before starting any maintenance and repairs; do not forget to protect against unlock by anybody else.
PREVENT OF COMMON DANGERS AND RISKS
RECOMMENDED SAFETY PRACTICES
3.8.4
3.8.5
PREVENT OF COMMON DANGERS AND RISKS
KIND OF DANGER OR RISK SOURCE OF DANGER OR RISK DANGER OR RISK
Danger caused
by moving parts
Fans, electric motors, pumps Danger of hurting
Danger produced
by electric contacts
Electrical parts, electric wires Danger of loosing one’ s life
Danger caused
by hot surfaces.
Hot water and steam coils, steam
humidiers
Danger of burning
Danger caused
by pipe or hose damage
Water and steam coils Water and steam
humidiers
Danger of burning from hot water or steam
Danger of electric shock caused by water
contacting electrical parts and cables.
Risk of corrosion.
Risk caused
by overspeed of fan
External frequency converter
Risk of damage of motor, fan and ductwork
Risk of excessive noise.
Risk caused
by mechanical resonance
Vibration isolators
Risk of damage or destruction
of air handling unit.
Risk of fail function
or programming
External frequency converter
Risk of overspeed of fan (see section
above “risk caused by overspeed of fan”)
Risk of mechanical resonance
(see section above “risk caused by
mechanical resonance”).
