Shutdown
Shutdown Shutdown
Shutdown
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensuresteady
voltage.Failuretofollowtheseprocedureswill
causevoltageuctuationsthatcandamage
electricalequipmentandvoidthewarranty.
1.Presstostopthepumps.
2.Turnoffallheatzones.
3.Relievepressure.See
PressureReliefProcedure,page47.
4.PresstoparktheComponentAand
ComponentBpumps.Theparkoperationis
completewhengreendotgoesout.Verifythe
parkoperationiscompletebeforemovingtonext
step.
5.Presstodeactivatethesystem.
6.Turnofftheaircompressor,airdryer,and
breathingair.
7.TurnthemainpowerswitchOFF.
Topreventelectricshockdonotremoveanycovers
oropentheelectricalenclosuredoorwhilethe
powerisON.
8.Closealluidsupplyvalves.
9.SetPRESSURERELIEF/SPRAYvalvesto
SPRAYtosealoutmoisturefromthedrainline.
10.Engagegunpistonsafetylockthencloseuid
inletvalvesAandB.
Fusion Fusion
Fusion
Probler Probler
Probler
48 334946H
