![Graco REACTOR 2 H-30 PHH132 [50/110] Before beginning repair](/img/pdf.png)
Graco REACTOR 2 H-30 PHH132 [50/110] Before beginning repair
![Graco REACTOR 2 H-30 PHH132 [50/110] Before beginning repair](/views2/1900582/page50/bg32.png)
Repair
Repair Repair
Repair
Repairingthisequipmentrequiresaccesstoparts
thatmaycauseelectricshockorotherseriousinjury
ifworkisnotperformedproperly.Besuretoshut
offallpowertoequipmentbeforerepairing.
Before Before
Before
Beginning Beginning
Beginning
Repair Repair
Repair
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensuresteady
voltage.Failuretofollowtheseprocedureswill
causevoltageuctuationsthatcandamage
electricalequipmentandvoidthewarranty.
1.Flushifnecessary.SeeFlushing,page49.
2.SeeShutdown,page48.
Pumpline Pumpline
Pumpline
Disassembly Disassembly
Disassembly
1.FollowthePressureReliefProcedure,page47.
2.Removeplugtting(206)fromlubecylinder
(205).
3.Insertclevispinremovaltool296607through
openinginlubecylinder(205)andscrewtoolinto
leftclevispin(219).Pullclevispinoutofclevis
(117).
4.Usehexkeytoremovefoursocketheadcap
screws(203)fromleftproportioningpump(202).
Removeleftproportioningpump.
5.Removelubecylinder(205).
6.Screwpinremovaltool296607intorightclevis
pin(219).Pullclevispinoutofclevis(117).
7.Usehexkeytoremovefoursocketheadcap
screws(203)onrightproportioningpump(202).
Removerightproportioningpump.
50 334946H
