Graco REACTOR 2 H-30 PHH132 [58/110] Replace belt
![Graco REACTOR 2 H-30 PHH132 [58/110] Replace belt](/views2/1900582/page58/bg3a.png)
Repair
Replace Replace
Replace
Belt Belt
Belt
1.FollowShutdown,page48.
2.Removetheheatercover(134)andthebelt
coverfasteners(19).
NOTICE NOTICE
NOTICE
Topreventdamagetotheovertemperature
switch,carefullyremovethecovers.
3.Liftcover(132)andloosenthebluebracket(131)
fasteners.Liftthebluebracket(133)offofthe
fastenersandsetaside.Removethebeltcovers
(131,132).
4.Removethebelt.
5.Installthenewbeltandreplacethecovers.
Replace Replace
Replace
Fluid Fluid
Fluid
Inlet Inlet
Inlet
Sensor Sensor
Sensor
NOTE: NOTE:
NOTE:
ForElitemodelsonly.
1.PerformShutdown,page48.
2.PerformPressureReliefProcedure,page47.
3.Disconnectinletsensorcablefromthe
uidinletassembly.Inspectcablefor
damageandreplaceifnecessary.See
ElectricalSchematics,page102.
4.Toreplacesensorcable:
a.CutanywiretiesanddisconnectfromHCM.
SeeElectricalSchematics,page102.
NOTICE NOTICE
NOTICE
Topreventdamagetocable,securecablewith
wireties.
5.Replacesensorandsecurewithwireties.
58 334946H
