AdvancedDisplayModule(ADM)Operation
Recipes Recipes
Recipes
Usethisscreentoaddrecipes,viewsavedrecipes,
andenableordisablesavedrecipes.Enabled
recipescanbeselectedattheHomeRunScreen.24
recipescanbedisplayedonthethreerecipescreens.
Add Add
Add
Recipe Recipe
Recipe
1.Press
andthenusetoselecta
recipeeld.Press
toenterarecipename
(maximum16characters).Presstoclearthe
oldrecipename.
2.Usetohighlightthenexteldandusethe
numberpadtoenteravalue.Press
tosave.
Enable Enable
Enable
or or
or
Disable Disable
Disable
Recipes Recipes
Recipes
1.Press
andthenusetoselectthe
recipethatneedstobeenabledordisabled.
2.Usetohighlighttheenabledcheckbox.
Presstoenableordisabletherecipe.
Cellular Cellular
Cellular
Screen Screen
Screen
UsethisscreentoconnecttheReactor2Apptothe
Reactor,todeterminethecellularsignalstrength,or
toresettheReactorKey.
Reset Reset
Reset
Reactor Reactor
Reactor
Key Key
Key
ResettingyourReactorKeypreventsotherusers
fromremotelychangingorviewingReactorsettings
withoutrstreconnectingtotheReactor.
1.OntheReactorADMCellularScreen,press
toresettheReactorkey.
2.Pressto
conrmresettingtheReactorkey.
3.ReconnectyourapptotheReactor.Seeyour
Reactor2Appinstallationmanual.
NOTE: NOTE:
NOTE:
AfterresettingyourReactorkey,alloperators
usingtheGracoReactor2Appmustreconnectto
theReactor.
NOTE: NOTE:
NOTE:
Forsecurityofwirelesscontrol,changethe
Reactorkeyonaregularbasisandwheneverthere
isaconcernaboutunauthorizedaccess.
