Startup
Startup Startup
Startup
Topreventseriousinjury,onlyoperateReactorwith
allcoversandshroudsinplace.
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensuresteady
voltage.Failuretofollowtheseprocedureswill
causevoltageuctuationsthatcandamage
electricalequipmentandvoidthewarranty.
1.Checkuidinletlterscreens.
Beforedailystartup,ensurethatthe
uidinletscreensareclean.See
FluidInletStrainerScreens,page64.
2.CheckISOlubricationreservoir.
ChecklevelandconditionofISOlubedaily.See
PumpLubricationSystem,page66.
3.UseAandBDrumLevelSticks(24M174)to
measurethemateriallevelineachdrum.If
needed,thelevelcanbeenteredandtrackedin
theADM.SeeAdvancedSetupScreens,page37.
4.Checkgeneratorfuellevel.
NOTICE NOTICE
NOTICE
Runningoutoffuelwillcausevoltage
uctuationsthatcandamageelectrical
equipmentandvoidthewarranty.Donotrun
outoffuel.
5.ConrmmainpowerswitchisOFFbeforestarting
generator.
6.Ensurethemainbreakeronthegeneratorisin
theoffposition.
7.Startthegenerator.Allowittoreachfulloperating
temperature.
8.Turn Turn
Turn
main main
main
power power
power
switch switch
switch
ON. ON.
ON.
TheADMwilldisplaythefollowingscreenuntil
communicationandinitializationiscomplete.
334945J
47
