MSI A520M PRO [15/166] Specifications

Specifications

CPU

Support 3rd Gen AMD Ryzen™ Desktop Processors and AMD

Ryzen™4000 G-Series Desktop Processors

Chipset

∙ AMD B550 Chipset (B550M PRO)

∙ AMD A520 Chipset (A520M PRO)

Memory

∙ 2x DDR4 memory slots, support up to 64GB*

▪ Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/

3000/ 3066/ 3200 MHz by JEDEC

▪ Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200

/3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+

MHz by A-XMP OC MODE

▫ 1DPC 1R max speed 4600 MHz

▫ 1DPC 2R max speed 3866 MHz

∙ Dual channel memory architecture

∙ Supports non-ECC UDIMM memory

∙ Supports ECC UDIMM memory (non-ECC mode)

∙ Supports un-buffered memory

* Please refer www.msi.com for more information on compatible memory.

Expansion Slot

∙ 1x PCIe x16 slot (PCI_E2)

▪ B550M PRO supports PCIe 4.0/3.0*

▪ A520M PRO supports PCIe 3.0

∙ 2x PCIe 3.0 x1 slots

* PCIe specifications may vary depending on the CPU installed.

Onboard Graphics

∙ 1x VGA port, supports a maximum resolution of 2048x1536

@50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz**

∙ 1x HDMI 2.1 port, supports a maximum resolution of

4096x2160 @60Hz*

∙ 1x DisplayPort 1.2 port, supports a maximum resolution of

4096x2160 @60Hz**

∙ Maximum shared memory of 16 GB

* Graphics specifications may vary depending on the CPU installed.

** Available for the processor with integrated graphics.

Continued on next page
