Gigabyte Z590 AORUS TACHYON [10/112] 2 product specifications
![Gigabyte Z590 AORUS TACHYON [10/112] 2 product specifications](/views2/1919716/page10/bga.png)
- 10 -
Hardware Installation
1-2 ProductSpecications
CPU LGA1200 package:
- 11th Generation Intel
®
Core
™
i9processors/Intel
®
Core
™
i7processors/
Intel
®
Core
™
i5 processors
- 10th Generation Intel
®
Core
™
i9processors/Intel
®
Core
™
i7processors/
Intel
®
Core
™
i5processors/Intel
®
Core
™
i3processors/
Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors*
* Limited to processors with 4 MB Intel
®
Smart Cache, Intel
®
Celeron
®
G5xx5 family.
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
Z590 Express Chipset
Memory 11th Generation Intel
®
Core
™
i9/i7/i5 processors:
- SupportforDDR43200/3000/2933/2666/2400/2133MHzmemory
modules
10th Generation Intel
®
Core
™
i9/i7 processors:
- SupportforDDR42933/2666/2400/2133MHzmemorymodules
10th Generation Intel
®
Core
™
i5/i3/Pentium
®
/Celeron
®
processors:
- SupportforDDR42666/2400/2133MHzmemorymodules
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor-Intel
®
HD Graphics support:
- 1xHDMIport,supportingamaximumresolutionof4096x2160@60Hz
* Support for HDMI 2.0 version and HDCP 2.3.
(Graphics specications may vary depending on CPU support.)
Audio Realtek
®
ALC1220-VB codec
* The back panel line out jack supports DSD audio.
Support for DTS:X
®
Ultra
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Intel
®
2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
Wireless
Communication
Module
Intel
®
Wi-Fi 6E AX210
- WIFIa,b,g,n,ac,ax,supporting2.4/5/6GHzcarrierfrequencybands
- BLUETOOTH 5.2
- Supportfor11ax160MHzwirelessstandardandupto2.4Gbpsdatarate
* Actual data rate may vary depending on environment and equipment.
