Hardware Installation
- 11 -
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is
populated, the PCIEX16 slot operates at up to x8 mode.
(The PCIEX16 and PCIEX8 slots conform to PCI Express 4.0 standard.)
(Note)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
1 x PCI Express x16 slot, running at x1 (PCIEX1)
(The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)
Multi-Graphics
Technology
Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface CPU:
- 1xM.2connector(Socket3,Mkey,type2260/2280/22110PCIe4.0x4/x2
SSD support) (M2A_CPU)
(Note)
Chipset:
- 2xM.2connectors(Socket3,Mkey,type2280/22110SATAandPCIe3.0
x4/x2SSDsupport)(M2P_SB)(M2M_SB)
- 6xSATA6Gb/sconnectors(SATA30~5)
* Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
Support for RAID 0, RAID 1, RAID 5, and RAID 10
Intel
®
Optane
™
Memory Ready
ASMedia
®
ASM1061 chip:
- 2xSATA6Gb/sconnectors(SATA36,7),supportingIDE/AHCImodeonly
USB Chipset:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2x2 support
- 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 4xUSB2.0/1.1portsavailablethroughtheinternalUSBheaders
ASMedia
®
USB 3.2 Gen 2 controller:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2 support, available through the
internal USB header
- 1 x USB 3.2 Gen 2 Type-A port (red) onboard
Chipset+Realtek
®
USB 3.2 Gen 1 Hub:
- 4 x USB 3.2 Gen 1 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x water cooling CPU fan header
4 x system fan headers
2 x system fan/water cooling pump headers
2 x addressable LED strip headers
2 x RGB LED strip headers
(Note) Supported by 11th Generation processors only.
