- 12 -
Hardware Installation
Internal
Connectors
3 x M.2 Socket 3 connectors
8 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C
®
header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 2 Type-A port (red)
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x noise detection header
2 x Thunderbolt
™
add-in card connectors
1 x Clear CMOS jumper
1 x power button (PW_SW)
1 x reset button (RST_SW)
1 x Clear CMOS button (CMOS_SW)
2 x BIOS switches (BIOS_SW)(SB)
1 x Cold Reset button (RTY_SW)
1 x Protection Mode button (LIMP_MODE)
1 x CPU Ratio up button (RATIO_UP)
1 x CPU Ratio down button (RATIO_DW)
1 x Prole A button (PROFILE_A)
1 x Prole B button (PROFILE_B)
1 x OC Trigger switch (TGR)
1 x LN2 Mode switch (LN2_SW)
1 x Enhanced LN2 Mode switch (LN2_OFFSET)
1 x Reserved switch (RSV_SW)
Back Panel
Connectors
1 x Q-Flash Plus button
1 x OC Ignition button
1 x PS/2 keyboard port
1 x PS/2 mouse port
2 x SMA antenna connectors (2T2R)
1 x HDMI port
1 x USB Type-C
®
port, with USB 3.2 Gen 2x2 support
3 x USB 3.2 Gen 2 Type-A ports (red)
4 x USB 3.2 Gen 1 ports
1 x RJ-45 port
1 x optical S/PDIF Out connector
5 x audio jacks
I/O Controller iTE
®
I/O Controller Chip
Hardware
Monitor
Voltage detection
Temperature detection
Fan speed detection
Water cooling ow rate detection
Fan fail warning
Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan
(pump) you install.
Noise detection
