- 21 -
2-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
7
4
17
13
2
516 21
4 1
5
14
10
19
4 4 8
9
6
3
20 15
11
12
5
1) ATX_12V/ATX_12V1
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3/4
5) SYS_FAN5/6/7_PUMP
6) CPU_OPT
7) EC_TEMP1/EC_TEMP2
8) CPU_LED
9) D_LED
10) LED_C
11) NOISE_SENSOR
12) BAT
13) SATA3 0/1/2/3
14) M2A_CPU/M2B_CPU/M2C_SB
15) F_PANEL
16) F_AUDIO
17) F_U320G
18) F_U32G2
19) F_U32
20) F_USB1
21) SPI_TPM
7
18
