- 9 -
Storage Interface CPU:
- 2 x M.2 connectors (Socket 3, M key, type 25110/2280 PCIe 5.0
(Note)
x4/x2
SSD support) (M2A_CPU, M2B_CPU)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD
support) (M2C_SB)
- 4 x SATA 6Gb/s connectors
RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, and RAID 10 support for SATA storage devices
USB CPU:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2 support
- 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
Chipset:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2x2 support, available through the
internal USB header
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
Chipset+ASMedia
®
USB 3.2 Gen 2 Controller:
- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
Chipset+USB 3.2 Gen 1 Hub:
- 4 x USB 3.2 Gen 1 ports on the back panel
Chipset:
- 2 x USB 2.0/1.1 ports available through the internal USB header
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x CPU fan/water cooling pump header
4 x system fan headers
3 x system fan/water cooling pump headers
1 x CPU cooler LED strip/RGB LED strip header
1 x addressable LED strip header
1 x RGB LED strip header
3 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C
®
header, with USB 3.2 Gen 2x2 support
1 x USB 3.2 Gen 2 Type-A port
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
2.0 module only)
1 x noise detection header
2 x temperature sensor headers
Voltage Measurement Points
1 x power button (PW)
1 x reset button (RST)
1 x Clear CMOS button (CMOS)
1 x Cold Reset button (RTY)
1 x Protection Mode button (LIMP_MODE)
1 x CPU Ratio Up button (CLK+)
(Note) Actual support may vary by CPU.
